Help CenterFigure 602Specif Ication and Reference Dimensions of Union
Related Products
-
Figure 402 606 Specif Ication and Reference Dimensions of UnionUS$ 10 - 100MOQ: 100 Pieces -
API Wellhead Tools Medium and Heavy Crudes Efficient Gas-water Sand SeparatorNegotiableMOQ: 1 Set
-
Figure 400 Specif Ication and Reference Dimensions of UnionUS$ 10 - 100MOQ: 100 Pieces
-
Figure 301 Specif Ication and Reference Dimensions of UnionUS$ 10 - 100MOQ: 100 Pieces
-
Figure 207 Specif Ication and Reference Dimensions of UnionUS$ 10 - 100MOQ: 100 Pieces
With resilient nitrile-butadiene rubber seal ring, this figure is used for sealing and protecting the steel-to-steel match.It is recommended for the connection of manifold and pipe and truck -mounted application and mud delivery. It may be used as pressureless seal union with butt weld Sch.80.
Nominal pipe |
Total length |
Pipck bore |
Nut radius |
Materials |
Weight |
||||||
Nut |
Part |
||||||||||
in |
mm |
in |
mm |
in |
mm |
in |
mm |
|
|
lbs |
kgs |
1 |
25.4 |
317/32 |
89.7 |
1/4 |
6.4 |
26/18 |
58.75 |
SF |
SF |
3.5 |
1.6 |
2 |
50.8 |
51/4 |
133.3 |
1/4 |
6.4 |
30/18 |
90.5 |
SF |
SF |
13.25 |
5.9 |
3 |
76.2 |
63/8 |
161.92 |
3/8 |
9.5 |
45/8 |
117.5 |
SF |
SF |
21.0 |
9.5 |
4 |
101.6 |
81/18 |
208.0 |
3/8 |
9.5 |
51/4 |
133.4 |
SF |
SF |
33.0 |
15.0 |
For figure 602, 6000PSI NSCWP, test pressure at 9000PSI with black nut and orange parts
1. Your inquiry related to our products or prices will be replied in 12 hours.
2. Well-trained and experienced staffs to answer all your inquiries.
3. Protection of your sales area, ideas of design and all your private information
standard package or according to customers needs
30% deposit by T/T before production, 70% balance should be paid by T/T before shipment. but we also accept L/C.
Contact Person: Eve Yue
Tel: 0086-546-7766986
Fax: 0086-546-7766986
Mobile: 0086-13280316878
Website:
Send Inquiry to This Supplier
