SA-YZ2*40A Hydraulic cable laying Tensioner for overhead line transmission
Application
SA-YZ2*40A Hydraulic cable laying Tensioner for overhead line transmission is adequate to tension releasing various conducts and earthwires, and it as one pull one or one pull four using.
Feature :
1. Bullwheel with wearproof MC nylon lining segments.
2. Infinitely variable tension control and constant tension conductor stringing .
3. Spring applied hydraulic released brake acts automatically in case of hydraulic failure to ensure safety .
4. Attached two sets of hydraulic power output interface to connect hydraulic reel stand.
Main component
1.Engine :Deutz air-cooled diesel engine .
2.Main pump and main motor : Rexroth(BOSCH)
3.Reducer : RR(Italian)
4.Radiator :AKG
5.Hydraulic instrument :WIKA
6.Hydraulic valve:Rexroth(BOSCH)
7.It can choose the Chinese air-cooled engine,the model is SA-YZ2*40B
8.According to needing, its can configure mobile control consoles.It is easy for one operator to control 2 machines simultaneously, which facilitates 4-conductorstringing operation using two machine. The control consoles order number is:07193
Technical Data of SA-YZ2*40A Hydraulic cable laying Tensioner for overhead line transmission
| Model Type | SA-YZ2*40A |
| Maximum Tension(KN) | 2*40 or 1*80 |
| Continuous Tension(KN) | 2*35 or 1*70 |
| Maximum speed(km/h) | 5 |
| Bullwheel bottom of groove diameter(mm) | Φ1500 |
| Number of groove | 2*5 |
| Maximum pullback(KN) | 2*40 or 1*80 |
| Maximum speedback(km/h) | 2*1.2 |
| Maximum suitable conductor diameter(mm) | Φ40 |
| Engine power/speed(kw/rpm) | 51/2500 |
| Dimensions(mm) | 4500*2200*2800 |
| Weight(kg) | 4850 |
