SA-YZ2*30 Hydraulic cable Tensioner for pulling or stringing
Application
SA-YZ2*30 Hydraulic cable Tensioner for pulling or stringing is adequate to tension releasing various conducts and earthwires, and it as one pull one or one pull two using.
Feature :
1. Bullwheel with wearproof MC nylon lining segments.
2. Infinitely variable tension control and constant tension conductor stringing .
3. Spring applied hydraulic released brake acts automatically in case of hydraulic failure to ensure safety .
4. Attached two sets of hydraulic power output interface to connect hydraulic reel stand.
Main component
1.Engine :Chinese famous brand aircooled engine .
2.Main pump and main motor : Rexroth(BOSCH)
3.Reducer : RR(Italian)
4.Radiator :AKG
5.Hydraulic instrument :WIKA
6.Hydraulic valve:Rexroth(BOSCH)
Technical Data of SA-YZ2*30 Hydraulic cable Tensioner for pulling or stringing
| Model Type | SA-YZ2*30 |
| Maximum Tension(KN) | 2*30 or 1*60 |
| Continuous Tension(KN) | 2*25 or 1*50 |
| Maximum speed(km/h) | 5 |
| Bullwheel bottom of groove diameter(mm) | Φ1200 |
| Number of groove | 2*5 |
| Maximum pullback(KN) | 2*30 or 1*60 |
| Maximum speedback(km/h) | 2*1.2 |
| Maximum suitable conductor diameter(mm) | Φ32 |
| Engine power/speed(kw/rpm) | 38/2500 |
| Dimensions(mm) | 4100*2100*2600 |
| Weight(kg) | 4000 |
