Crawler Excavator

Zhengzhou Timeway Machine Tool Co., Ltd.
Crawler Excavator thumbnail-1
Crawler Excavator photo-1
Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Brand Name:
TIMAC
Model Number:
EXCAVATOR 330E
Condition:
New
Contact Supplier Request Quote Chat Now
Payment & Shipping
Payment Methods:
Port of Shipment:
China port
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Brand Name TIMAC
Model Number EXCAVATOR 330E
Condition New
Moving Type Crawler Excavator
Operating Weight 33400kg
Bucket capacity 1.45M3
Maximum Digging Height 10390mm
Maximum Digging Depth 7490mm
Machine Weight 33400kg
Max Digging Radius 11220mm

Crawler Excavator



DESCRIPTIONSPECIFICATON
MODELEXCAVATOR 330E
Working weight33400kg
Bucket capacity1.45M3
Track width600mm
Transport dimension 11250*3190*3430(mm)
Overall dimensionLength of track on ground3730mm
Ground clearance of counter weight1180mm
Tail swing radius3430mm
Total length11250mm
Total height 3430mm
Total width 3190mm
Track gauge2590mm
Min. ground clearance540mm
Track width600mm
Track height1040mm
Working rangeMax. working radius11220mm
Max. digging depth7490mm
Max. vertical digging depth6520mm
Max. digging height10390mm
Max. dumping height7320mm
Min. swing radius4295mm
PerformanceGround pressure68.5Kpa
Swing speed11r/min
Travelling speed high/low4.5/3.1km/h
Grade ability35°
Noise inside the cab ≤80db(A)
Fuel tank545L
EngineCompany Cummins C8.3(6CTAA)
Type 6 cylinder, inline, turbocharged
Rated horsepower168KW/2000rpm
Bore-stroke114*134.9mm
Displacement8.29L
Min. fuel consumption≤228g/kw.h
Max. torque /revolution975Nm/1400rpm
Main hydraulic pumpCompany KAWASAKI
Type K3V140DT-1CMR-9N2P
Rated pressure34.3Mpa
Max. delivery 271*2L/min
Pump type 2*variable flow axial piston pump+1 gear pump
Method of power adjustmentGross power adjustment + variable power + negative flow control
SwingCompany KAWASAKI
motorType M5X180CHB-10A-20A/260-RG16S21D18A-140
 Rated pressure 25.5Mpa
 Max. delivery 180.1cc/rev
Travel  motorCompany JAPAN NEBTESCO
Type GM60VA
Rated pressure 35.0MPa
Max. delivery 290.7/170.1cc/rev
The pressure of hydraulic control systemWorking part31.4Mpa
Traveling part31.4Mpa
Hydraulic oil tank210L
Hydraulic oil filterDouble filter in the tank
Swing systemSwing speed 11RPM
Type constant closed disc type brake with buffer function
Chassis systemTrack featurethree grouser, grease tension
Track rollers and carrier rollersFloating sealing
Quantity2 carrier rollers and 9 track rollers
Brake typeHydraulic brake
Working equipmentArm length 6450mm
Rod length3000mm
Bucket digging force≥185KN
Rod crowed force≥160KN
Driving cabCab Imported cab, SAE certificate
Air-conditionerJiangsu chuang dao
Seat Direction adjustment
Instrument panel hour meter, engine revolution, oil temperature, water temperature, oil pressure.
ElectricPower24V
instrumentCompany XUZHOU KANG DA
 Battery VARTA  160A.H





Standard equipmentEngineCummins C8.3(6CTA)
Hydraulic pumpKAWASAKI
Control valveKAWASAKI
Swing motor KAWASAKI
Travel motor JAPAN NEBTESCO
Cylinder HENG LI
Electrical InstrumentImported
Driving cabLuxury
Seat Grammer
Painting NIPPON
