Crawler Excavator

Zhengzhou Timeway Machine Tool Co., Ltd.
Crawler Excavator thumbnail-1
Crawler Excavator photo-1
Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Brand Name:
TIMAC
Model Number:
EXCAVATOR 210LC
Condition:
New
Contact Supplier Request Quote Chat Now
Payment & Shipping
Payment Methods:
Port of Shipment:
China port
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Brand Name TIMAC
Model Number EXCAVATOR 210LC
Condition New
Moving Type Crawler Excavator
Operating Weight 21000kg
Bucket capacity 0.90M3
Maximum Digging Height 9489mm
Maximum Digging Depth 6057 mm
Machine Weight 21000KG
Max Digging Radius 9944mm

Crawler Excavator



DESCRIPTIONSPECIFICATON
MODELEXCAVATOR 210LC
Working weight21000kg
Bucket capacity0.90M3
Track width600mm/800mm
Transport dimension 9540*2980*3020(mm)
Overall dimensionLength of track on ground3650mm
Ground clearance of counter weight1070mm
Total length9540mm
Total height 3020mm
Total width 2980mm
Track gauge2380mm
Min. ground clearance460mm
Track width600mm
Track height964mm
Tail swing radius2750mm
Working rangeMax. working radius9944mm
Max. digging depth6638 mm
Max. vertical digging depth6057 mm
Max. digging height9489mm
Min. swing radius3542mm
 Max. dump height6672mm
PerformanceGround pressure44Kpa/35Kpa
Swing speed12r/min
Travelling speed high/low5.4/3.1km/h
Grade ability35°
Noise inside the cab ≤80db(A)
Fuel tank360L
EngineCompany Cummins 6BT5.9
Type 6 cylinder, inline, turbocharged
Rated horsepower112KW/1950rpm
Bore-stroke102*120mm
Displacement5.9L
Min. fuel consumption≤228g/kw.h
Max. torque /revolution597Nm/1600rpm
Main hydraulic pumpCompany KAWASAKI
Type K3V112DT-1X7R-9N2P-1V
Rated pressure31.4Mpa
Max. delivery 208*2L/min
Pump type 2*variable flow axial piston pump+1 gear pump
Method of power adjustmentGross power adjustment + variable power + negative flow control
SwingCompany KAWASAKI
motorType M5X130CHB-10A-12B/260-RG10D20K1
 Rated pressure 25.5Mpa
 Max. delivery 129.2c/rev
Travel  motorCompany JAPAN NEBTESCO
Type GM35VL-A-75/130
Rated pressure 34.81MPa
Max. delivery 130.4cc/rev (max)
The pressure of hydraulic control systemWorking part31.4Mpa
Traveling part31.4Mpa
Hydraulic oil tank160L
Hydraulic oil filterDouble filter in the tank
Swing systemSwing speed 11.5RPM
Type constant closed disc type brake with buffer function
Chassis systemTrack featurethree grouser, grease tension
Track rollers and carrier rollersFloating sealing
Quantity2 carrier rollers and 7 track rollers
Brake typeHydraulic brake
Working equipmentArm length 5700mm
Rod length2800mm
Bucket digging force120KN
Rod crowed force95KN
Driving cabCab Imported cab, SAE certificate
Air-conditionerJiangsu chuang dao
Seat Direction adjustment
Instrument panel hour meter, engine revolution, oil temperature, water temperature, oil pressure.
ElectricPower24V
instrumentCompany XUZHOU KANG DA
 Battery VARTA  160A.H



Standard equipmentEngineCummins 6BT5.9
Hydraulic pumpKAWASAKI
Control valveKAWASAKI
Swing motor KAWASAKI
Travel motor JAPAN NEBTESCO
Cylinder HENG LI
Electrical InstrumentImported
Driving cabComfortable
Seat Grammer
Painting NIPPON
