14" (360mm) Hollow Spindle Threading Lathe Q-360S
US$ 50,000 - 150,000
MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Type:
Horizontal
CNC or Not:
Normal
Payment & Shipping
Payment Methods:
Port of Shipment:
China Port
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
14" Large Spindle Bore Pipe Thread Lathe (Oil Country Lathe)US$ 1,000 - 100,000MOQ: 1 Set -
Oil Country Lathe Pipe Thread Cutting LatheUS$ 10,000 - 100,000MOQ: 1 Set
-
CNC Roll Processing Machine (ROLL NOTCHING & ENGRAVING LATHE)US$ 45,000 - 100,000MOQ: 1 Set
-
CNC Roll Turning LatheNegotiableMOQ: 1 Set
-
CNC Pipe Threading Lathe MachineUS$ 25,000 - 60,000MOQ: 1 Set
Condition
New
Type
Horizontal
CNC or Not
Normal
Automatic Grade
Manual
Max. Swing Diameter
1000mm
Brand Name
TIMAC
Model Number
Q-360S
Voltage
380v 50hz
Power(W)
22kw
Dimension(L*W*H)
As actual
Weight
As actual
Certification
CE ISO
After-sales Service Provided
Engineers available to service machinery overseas
Conventional Pipe threading lathe
Q-280S Q-360S Q-460S
Main Outlook
Product Description
Application:
14" (360mm) Hollow Spindle / Conventional Pipe Threading Lathe
We, Timeway Machine sold 6", 8", 10", 14", 18" hollow spindle Conventional oil country lathes designed to perform all sizes of the threads used in the oil & gas industry; center height 385mm, 500mm, 550mm, 650mm; distance between centres from 1500mm up to 9000mm; 3-jaw self-centering chuck or 4-jaw independent chuck on both sides of gear box. All machines are in conformity to the CE norms.
Features:
- This lathe meets the special requirements of users in the petroleum, geological, mining and chemical industries, and in agricultural irrigation and drainage.
- It is able to cut various straight and taper pipe threads of union joints, drill rods, casting pipes, drain pipes, well castings and water pump pipes more economically and efficiently as compared with the engine lathe, however, it may serve as an engine lathe to cut various metric, withworth and module threads, shafts and disks.
- The machine tool is equipped with a tapering unit which can work out a 1:4 taper.
- The machine tool is able to cut both metric and with threads without changing the translating gear.
- Dripping worm in the apron can protect the mechanisms of the lathe automatically.
- The guide way is hardened and finely finished.
- The great power of the machine is competent at heavy load and power cutting.
- The floor center rest can be moved freely as required by the user.
- Center rest is provided with an adjustable clamp unit for long pipes, greatly reducing intensity of labor.
- Double 4-jaw chucks offer free clamp of both short and long pipes.
Technical Parameter:
| Specification | Unit | Q-280S | Q-360S | Q-460S |
| Diameter of spindle bore | mm | Φ280 | Φ360 | Φ460 |
| Max. swing over bed | mm | Φ1000 | Φ1000 | Φ1250 |
| Max. swing over tool post | mm | Φ700 | Φ640 | Φ890 |
| Max. workpiece lengt between centers | mm | 1500/2000/3000/4000/5000/6000/7000/8000/9000 | ||
| Max. turning length. | mm | 1300/1800/2800/3800/4800/5800/6800/7800/8800 | ||
| Max. load capacity between two centers | kg | 4000 | 6000 | 6000 |
| Width of bed | mm | 600 | 755 | 970 |
| Spindle speed step | steps | 8 | 8 | 8 |
| Spindle speed range | rpm | 5-315 | 6.3-315 | 6.3-315 |
| Main motor power | kw | AC18.5 | AC22 | AC30 |
| Number and range of Metric thread | mm | 44 kinds, 1-120 | ||
| Number and range of Inch thread | T.P.I. | 37 kinds, 30-11/8 | ||
| Number and range of Module thread | mm | 46kinds, 0.5-60 | ||
| Number and range of Pitch thread | D.P. | 46kinds, 0.5-60 | ||
| Tool post station | - | Vertical 4-station | ||
| Tool section | mm | 32x32 | 45x45 | 45x45 |
| Diameter of tailstock sleeve | mm | Φ120 | Φ160 | Φ160 |
| Tailstock taper | - | Morse No.6 | Metric No.80 | Metric No.80 |
| Tailstock quill travel | mm | 300 | 300 | 300 |
| Rapid motor power | kw | 1.5 | 1.5 | 1.5 |
| Coolant pump power | kw | 0.15 | 0.15 | 0.15 |
Standard Configuration:
- 4-jaw chuch(front & rear)
- Steady rest
- Follow rest
- Taper turning attachment
- Oil gun
- Coolant system
- Working light
- Electric tailstock
- General tools
- Foundation bolts
- Operation manual(English edition)
Detail Images
Q-280S Series Photos:
Q-360S Series Photos:
Q-460S Series Photos:
