CNC Roll Processing Machine (ROLL NOTCHING & ENGRAVING LATHE)

Name: CNC Roll Processing Machine (ROLL NOTCHING & ENGRAVING LATHE)
Brand: Timac
SKU: 140798190
Availability: InStock

Zhengzhou Timeway Machine Tool Co., Ltd.

US$ 45,000 - 100,000 MOQ: 1 Set

Key Specifications

Condition:

New

Type:

Horizontal

CNC or Not:

CNC

Payment & Shipping

Payment Methods:

Port of Shipment:

China port

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Type Horizontal

CNC or Not CNC

Automatic Grade Automatic

Max. Swing Diameter 500

Place of Origin Henan, China

Brand Name Timac

Model Number RPK-500CJ

Voltage as requirement

Power(W) 11KW

Dimension(L*W*H) 4300x1750x1800mm

Weight 5980kg

Certification ISO9001:2008, CE

After-sales Service Provided Engineers available to service machinery overseas

Specifications

CNC Roll Processing Machine
ROLL NOTCHING & ENGRAVING LATHE

RPK-500CJ is a professional multi-Function CNC Roll Processing Machine used for machining ribs (notching) and engraving letter & logo on roll.

It’s equipped with famous brand SIEMENS Sinumerik802C CNC controller

& YASKAWA servomotors.

SIEMENS Sinumerik 802C guarantees the advance function & stable quality

for CNC and it offers 4-axes controls and 3 axis simultaneous movement.

Specificaion	RPK-500CJ
Max. Diameter of work piece	Ø500mm
Max. Length of work piece	2500mm
Suitable thread specification	10-40mm
Max. Spindle speed of flyer cutting milling head:	550rpm
Max. Spindle speed of swivel milling head:	2850rpm
Spindle bore of headstock:	MT#5
Headstock chuck (4 jaw chuck)	400mm
Main power of swivel head	1.1kw(380v)
Work piece swivel feed speed	50-600º/Min
Rapid work piece feed speed:	4000º/Min
Swivel speed of swivel head	40-600º/Min
Coolant pump motor	120w(380v)
CNC control system	SIEMENS Sinumerik802C
CNC control system power	220v/50hz
Min. programming setting unit	0.001mm; 0.001º
Output torque of servo motor	1) X axis (flyer cutter axis): 28.4N.m;
	2) Z axis (Swivel axis): 8.34N.m
	2) Y axis (roll axis): 11.5N.m
	3) C axis (feed axis): 11.5N.m
Overall dimension: (machine body) (LxWxH)	4050x1670x1500mm
Overall dimension: (electrical cabinet) (LxWxH)	890x660x1600mm
Net weight (machine + electrical cabinet)	5200kg + 220kg
Gross weight (machine + electrical cabinet)	5700kg + 280kg
Packing size (machine unit) (LxWxH)	4300x1750x1800mm
Packing size (Electrical cabinet) (LxWxH)	1000x800x1800mm
