Auoto-feeding Drilling (Milling) Machine

Name: Auoto-feeding Drilling (Milling) Machine
Brand: TIMAC
SKU: 140796982
Availability: InStock

Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)

Key Specifications

Condition:

New

CNC or Not:

Normal

Brand Name:

TIMAC

Zhengzhou Timeway Machine Tool Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

China port

Delivery Detail:

Delivery time depends on order quantity.

Condition New

CNC or Not Normal

Brand Name TIMAC

Model Number TRAPANO-4, TRAPANO-5

Specifications

Auoto-feeding Drilling (Milling) Machine

Auoto-feeding Drilling (Milling) Machine

The spindle head can rotated 360 degrees and tilted 45degrees

Model	Unit	TRAPANO-4	TRAPANO-5
Max. Drilling capacity	mm	(Iron)40 (Steel)32	(Iron)45 (Steel)32
Width of face milling	mm	80	80
Diameter of vertical milling	mm	22	28
Diameter of column	mm	115
Spindle travel	mm	110	110
Distance spindle axisto column generating line	mm	261.5	260
Max.Distance spindle nose to table	mm	450	475
Spindle taper		MT4 or R8	MT4
Spindle speeds range	r/min	50-1250	50-1250
Spindle speeds series		6	6
Spindle feeds	mm/r	0.12, 0.18, 0.25	0.12, 0.18, 0.25
Dimension of worktable surface	mm	730x210 or 820x240	730x210 or 820x240
Table travel	mm	450x170 or 540x170	450x170 or 540x170
Dimension of base	mm	605x400	604x558
Overall height	mm	1100	1100
Main motor	W	750 or 1100	750 or 1100
Coolant motor	W		40
G.W/N.W	kg	370/330	385/345
Packing dimension	mm	860x740x1160/970x770x1160	860x740x1160/970x770x1160
