Home > Manufacturing & Processing Machinery > Machine Tools > Drilling Machine > Auto-feeding Drilling(Milling) Machine
Negotiable
MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
CNC or Not:
Normal
Brand Name:
TIMAC
Payment & Shipping
Payment Methods:
Port of Shipment:
China port.
Delivery Detail:
Delivery time depends on order quantity.
Related Products
Condition
New
CNC or Not
Normal
Brand Name
TIMAC
Model Number
TRAPANO-2
Specifications
Auto-feeding Drilling(Milling) Machine
Model | Unit | TRAPANO-2 |
Max. Drilling capacity | mm | (Iron)40 (Steel)32 |
Width of face milling | mm | 80 |
Diameter of vertical milling | mm | 22 |
Diameter of column | mm | 115 |
Spindle travel | mm | 110 |
Distance spindle axisto column generating line | mm | 261.5 |
Max.Distance spindle nose to table | mm | 450 |
Spindle taper |
| MT4 or R8 |
Spindle speeds range | r/min | 50-1250 |
Spindle speeds series |
| 6 |
Spindle feeds | mm/r | 0.12, 0.18, 0.25 |
Dimension of worktable surface | mm | 730x210 or 820x240 |
Table travel | mm | 450x170 or 540x170 |
Dimension of base | mm | 605x400 |
Overall height | mm | 1100 |
Main motor | W | 750 or 1100 |
Coolant motor | W |
|
G.W/N.W | kg | 370/330 |
Packing dimension | mm | 860x740x1160/970x770x1160 |
