Radial Drilling Machine

Radial Drilling Machine thumbnail-1
Radial Drilling Machine photo-1
Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
CNC or Not:
Normal
Brand Name:
TIMAC
Contact Supplier Request Quote Chat Now
Zhengzhou Timeway Machine Tool Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
China port
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
CNC or Not Normal
Brand Name TIMAC
Model Number RL310, RL410

Specifications

Radial Drilling Machine.

 1.Radial Drilling Machine.
2.Use drilling, counter boring, spot facing reaming, tapping.

3. Hydraulic transmission

4. Hydraulic clamping

5. Hydraulic pre-selection

6. Hydraulic speed exchanging

Specification

Unit

RL310

RL410

Max. Drilling capacity

mm

32

40

Distance spindle axis to column generating line

mm

200-1000

200-1000

Diameter of column

mm

240

240

Spindle taper



MT4

MT4

Spindle travel

mm

250

250

Spindle speeds range

r/min

71-1800

71-1800

Spindle speeds series



8

8

Range of spindle feeds

mm/r

0.13-0.54

0.13-0.54

Spindle feeds



4

4

Distance spindle nose to working surface of base

mm

264-1064

264-1064

Diamension of worktable

mm

400X450X400

400X450X400

Dimension of base

mm

1500X740X160

1500X740X160

Overall size

mm

1730X750X2360

1730X750X2360

Power of main motor

kw

2.2

3

G.W/N.W

kg

1700/1400

1700/1400

Packing dimension

mm

1870X970X2200

1870X970X2200



Standard accessories:
Box shape worktable
Taper sleeve
Tool releasing wrench
Drift
Eyelet bolts



Optional accessories:
Quick instead chuck
Tapping chuck
Grease gun
