Radial Drilling Machine

Radial Drilling Machine thumbnail-1
Radial Drilling Machine photo-1
Negotiable MOQ: 2 Sets (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
CNC or Not:
Normal
Brand Name:
TIMAC
Contact Supplier Request Quote Chat Now
Zhengzhou Timeway Machine Tool Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
China port.
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
CNC or Not Normal
Brand Name TIMAC
Model Number RL410A

Specifications

Radial Drilling Machine.

1. Radial Drilling Machine.
2. Use for drilling, counterboring, tapping ect.

3. Mechanical transmission

4. Mechanical clamping

5. Mechanical speed exchanging.



Specification

Unit

RL410A

Max. Drilling capacity

mm

40

Distance spindle axis to column generating line

mm

320-1020

Diameter of column

mm

200

Spindle taper



MT4

Spindle travel

mm

240

Spindle speeds range

r/min

75-1220

Spindle speeds series



6

Range of spindle feeds

mm/r

0.1-0.25

Spindle feeds



3

Distance spindle nose to working surface of base

mm

120-860

Diamension of worktable

mm

400X400X350

Dimension of base

mm

1370X700X160

Overall size

mm

1600X720X1885

Power of main motor

kw

1.5

G.W/N.W

kg

1450/1230

Packing dimension

mm

1750X770X2100



Standard accessories:
Box shape worktable
Taper sleeve
Tool releasing wrench
Drift
Eyelet bolts

Optional accessories:
Quick instead chuck
Tapping chuck
Grease gun
