Help CenterHeavy-duty Radial Drilling Machine
Related Products
Specifications
Radial Drilling Machine1.Radial Drilling Machine
2. Main gears are machined by gear grinding, the machine ensuring precision and low noise.
Specification |
Unit |
RD500 |
Max. Drilling capacity |
mm |
50 |
Distance spindle axis to column generating line |
mm |
350-1250 |
Diameter of column |
mm |
350 |
Spindle taper |
|
MT5 |
Spindle travel |
mm |
315 |
Spindle speeds range |
r/min |
25-2000 |
Spindle speeds series |
|
16 |
Range of spindle feeds |
mm/r |
0.04-3.2 |
Spindle feeds |
|
16 |
Distance spindle nose to working surface of base |
mm |
350-1220 |
Diamension of worktable |
mm |
630x500x500 |
Dimension of base |
mm |
2050x1000x200 |
Overall size |
mm |
2150x1060x2650 |
Power of main motor |
kw |
4 |
G.W/N.W |
kg |
3500/3100 |
Packing dimension |
mm |
240x112x252 |
Standard accessories:
Box shape worktable
Taper sleeve
Tool releasing wrench
Drift
Eyelet bolts
Optional accessories:
Quick instead chuck
Tapping chuck
Grease gun
