Vertical Turret Miller , Swivel Head Milling Machine For Sale
- 50 Set / Sets per Month
- China Port
- T/T
- CNC Milling Machines,Mini CNC Milling Machines,DIY CNC Milling Machines,Hobby CNC Milling,DIY milling
- Benchtop CNC Mill, desktop cnc mill, Compact CNC, educational cnc, prototype cnc, cnc for school, training cnc
- CNC Milling Machines,Mini CNC Milling Machines,DIY CNC Milling Machines,Hobby CNC Milling,DIY milling
- Small CNC Milling Machine for School, Hobbist,Prototype,DIY
- YORNEW Desktop CNC Lathe Machine, education cnc, vocation cnc, hobby cnc, diy cnc
- Industrial 4.0 intelligent manufacturing production line, FMS, CIM, training system
Product Details
Condition: | New | Brand Name: | TIMAC | Model Number: | M250C/D,M300,M330,M330A |
Type: | Vertical | CNC or Not: | Normal | Voltage: | as customer's request |
Dimension(L*W*H): | 1516*1550*2080mm | Weight: | 1590-2350KG | Certification: | CE norms, ISO9001 |
Warranty: | 1year | After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
Vertical Turret Miller , Swivel Head Milling Machine For Sale
Features:
M250C:
*Rectangular guide ways on Y and Z axis;
*The guide way on saddle is lined with TF wearable material;
*5HP milling head motor and quill diameter is 100mm;
*Fixed structure is used to connect the mill head without adapter;
M250D:
*Rectangular guide ways on Y and Z axis;
*The guide way on saddle is lined with TF wearable material;
* 5HP milling head motor and quill diameter is 100mm.
M250U:
*Rectangular guide ways on Y and Z axis;
*X, Y axis adopt auto feed gear box; Feed motor: 250w; Feed rate: 15, 23, 33, 48, 78, 114, 166, 257;
*The work table surface and 3 axis guide way are hardened and precision ground.
M300:
*Rectangular guide ways on Y and Z axis;
*The guide way on saddle is lined with TF wearable material;
* 5HP milling head motor and quill diameter is 100mm;
*The work table surface and 3 axis guide way are hardened and precision ground;
*Z axis adopts high speed lifting motor.
M300A:
*Rectangular guide ways on Y and Z axis;
*The guide way on saddle is lined with TF wearable material;
*5HP milling head motor and quill diameter is 100mm;
*The work table surface and 3 axis guide way are hardened and precision ground;
*Z axis adopts high speed lifting motor;
*Fixed structure is used to connect the mill head without adapter;
M330:
*Rectangular guide ways on Y and Z axis;
*The guide way on saddle is lined with TF wearable material;
* 5HP milling head motor and quill diameter is 100mm;
*The work table surface and 3 axis guide way are hardened and precision ground;
*Z axis adopts high speed lifting motor.
* Super saddle structure.
M330A:
*Rectangular guide ways on Y and Z axis;
*The guide way on saddle is lined with TF wearable material;
*5HP milling head motor and quill diameter is 100mm;
*The work table surface and 3 axis guide way are hardened and precision ground;
*Z axis adopts high speed lifting motor.
*Super saddle structure;
*Fixed structure is used to connect the mill head without adapter.
Standard Accessories:
Draw bar, Electric box, Working light, Hand Oil pump, Tool & tool box
Optional Accessories:
Digital readout sysytem(DRO), Machine vise, Power feed unit, Gear box power feed, Clamping kits, ISO30/ISO40 collect chuck, R8 collect chuck, Oil collecting plate, Plastic splash guard, Cooling system.
Parameters:
Specification | Unit | M250C | M250D | M300 | M300A | M330 | M330A | |
Table size | mm | 254×1270 | 305×1370 | 330×1370 | ||||
254×1370 | 305×1500 | 330×1500 | ||||||
Longitudianl travel | mm | 850/950 | 870/1000 | 740/1000 | ||||
Cross travel | mm | 420 | 380 | 368 | ||||
Vertical travel | mm | 420 | 420 | 450 | ||||
T-slot(NO.& Size) | mm | 3×16 | ||||||
Ram travel | mm | 470 | 500 | |||||
Distance from spndle to table | mm | 0-420 | 0-435 | 0-450 | ||||
Taper of spindle hole | Standard ISO40 | |||||||
Spindle travel | mm | 127 | ||||||
Spindle speed | rpm | Standard:step16speed 50HZ:65-4500 60HZ:80-5440 | ||||||
Optional:Variable speed 65-3750 | ||||||||
Auto.feed of quill | mm/r | 3steps:0.04(0.0015")/0.08(0.003")/0.15(0.006") | ||||||
Spindle motor | kw/HP | 3.75kw/5HP | ||||||
Head Swivel | 90º | |||||||
Head tilting | fix | 45º | fix | 45º | fix | |||
Dimension of package | One | mm | 1516×1550×2080 | 1566×1650×2080 | 1800×2016×2180 | |||
Two | mm | 1650×1790×2170 | 1720×1800×2175 | 1800×2200×2180 | ||||
Gross weight | kg | 1590 | 1700 | 1750 | 2300 | 2350 |
