CNC Vertical Machining Center

CNC Vertical Machining Center thumbnail-1
CNC Vertical Machining Center photo-1
Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
Type:
Vertical
Brand Name:
TIMAC
Contact Supplier Request Quote Chat Now
Zhengzhou Timeway Machine Tool Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
China port
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Type Vertical
Brand Name TIMAC
Model Number VMC500

CNC Vertical Machining Center(VMC)



Features:

3-axis precision linear guide-ways;

FANUC 0i mate-MD CNC system;

High precision and speed spindle unit;

Umbrella type magazine with 10 tools capacity;

Separated type electronic hand wheel (MPG);

RS232 interface;

Oil and water separated design;

Internal settled auto. chip conveying units;

Interval auto-lubricating;

Full splash guard;

Tricolor alarm light;

Operation manuals (English edition).



Specification Unit VMC500
X-axis travel mm 500
Y-axis travel mm 320
Z-axis travel mm 400
Spindle nose to table mm 125-520
Spindle center to column guideway face mm 360
Rapid feeding of X,Y axis mm/min 24000
Rapid feeding of Z axis mm/min 18000
Feeding speed mm/min 1-5000
Table size  mm 800x320
Max.loading capacity of table kg 300
T-slot NO./width/distance of table   3/14/100
Spindle max.speed r/min 10000
Main motor rated power kw 3.7/5.5
Spindle nose taper   BT30
Magazine capacity pcs 10
Magazine style   Umbrella
Max.diameter of tool mm 60
Max.length of tool mm 200
Max. weight of tool kg 5
Pneumatic press mpa 0.6
N.W kg 2600
Overall dimension mm 1600x1840x2110



CNC vertical machining center CNC vertical machining center
