Specifications
CNC vertical and horizontal fixed beam gantry-type machining center.Features:
1. The machine has a twin-spindle, two processing channels, both online processing, to achieve five-axis four linked.
2. And the most spindle speed is 4000r.p.m
3. Side milling spindle.
4. Chain-type tool magazine capability 32 tools
5.. Suitable for aerospace, automotive, textile machinery, tooling, packaging machinery, mineral machinery, precision machining of large workpieces. Can be done automatically milling, drilling, boring, tapping, and other procedures of a complex process
Soecification |
Unit |
TM2415A |
X-axis travel |
mm |
5100 |
Y-axis travel |
mm |
2500 |
Z-axis travel |
mm |
1000 |
Horizontal milling head cross travel |
mm |
500 |
Horizontal milling head vertical travel |
mm |
500 |
Worktable size |
mm |
5500x2000 |
Max. load of workable |
kg |
8000 |
Number of T-slot |
qty |
9 |
Width of T-slot |
mm |
28H8 |
Spindle taper(horizontal/ vertical) |
|
ISO50 |
Spindle speed range |
r.p.m |
10-30000 |
Distance from spindle nose to worktable surface |
mm |
150-1150 |
Distance fron horizontal spindle axis to worktable surface |
mm |
0-500 |
Feed speed on X, Y axis |
mm/min |
2-3000 |
Rapid feed on X, Y axis |
mm/min |
1-10000 |
Spindle motor power(horizontal/vertical) |
kw |
15/18.5 |
Feeding motor power |
kw |
9/4/7/3/3 |
Positioning accuracy |
mm |
0.015 |
Repear positioning accuracy |
mm |
0.0075 |
Overall dimension |
mm |
12890x6075x3440 |
Machine weight |
kg |
55000 |
