Vertical Machining Center (VMC)
Features:
1. Taiwan HIWIN linear guideways for X,Y axes, sliding guideway for Z axis, to make sure the machining accuracy and rigidity;
2. Taiwan high speed, high precision spindle unit (8000rpm);
3. Taiwan tool magazine with 16 stations, reliable and quick for tools exchange;
4. Cooling system adopts large fluid and high pressure coolant pump, to make sure the enough cooling under the high speed processing condition;
5. The machine adopts full close type protection guard; make the clean circumstance and safety of the operator.
6. Interval automatic type lubrication system is equipped, to make sure smooth process and long life.
Model |
Unit |
VMC846 |
VMC1050 |
Table tavle(X,Y,Z) |
mm |
800x460x500 |
1000x510x510 |
Table size |
mm |
800x460 |
1100x510 |
Number/Width/Distance of T-slot |
mm |
3-18-150 |
5-18-100 |
Max. load of table |
kg |
500 |
800 |
Distance from spindle nose to table surface |
mm |
150-650 |
120-630 |
Distance from spindle axis to vertical guideway |
mm |
510 |
600 |
Rapid feed speed |
m/min |
18 |
18 |
Feed speed |
mm/min |
2-4000 |
2-4000 |
Taper of spindle |
|
BT40 |
BT40 |
Spindle speed range |
rpm |
40-8000 |
40-8000 |
Spindle motor power |
kw |
7.5 |
7.5/11 |
Tool magazine capacity |
pc |
16 |
16 |
Max. weight of tool |
kg |
8 |
8 |
Max. dimension of tool |
mm |
130x250 |
130x250 |
Positioning accuracy |
mm |
±0.015 |
±0.012 |
Repeat positioning accuracy |
mm |
±0.0075 |
±0.005 |
Min. time of tool exchange |
sec |
3 |
3 |
Overall dimension |
mm |
2500x2260x2300 |
2900x2260x2620 |
Machine weight |
kg |
4650 |
5870 |
Standard items:
FANUC 0i mate MD controller;
FANUC servo main motor;
FANUC servo feed motors on three axes;
Taiwan 16 stations armless type tool magazine;
RS232 I/O interface;
Movable electronic handwheel (MPG);
Spindle blowing chips system;
Work light;
Tricolor alarm light;
Tools;
Foundation bolts;
Operational manuals(Mechanical & Electric parts).
Optional items:
FANUC 0i MD controller;
Siemens controller;
MITSUBISH controller;
China made GSK controller;
The 4th axis;
Taiwan 24 stations arm type tool magazine;
Automatic chip conveyor.
