Specification |
Unit |
VMC500 |
X-axis travel |
mm |
500 |
Y-axis travel |
mm |
320 |
Z-axis travel |
mm |
400 |
Spindle nose to table |
mm |
125-520 |
Spindle center to column guideway face |
mm |
360 |
Rapid feeding of X,Y axis |
mm/min |
24000 |
Rapid feeding of Z axis |
mm/min |
18000 |
Feeding speed |
mm/min |
1-5000 |
Table size |
mm |
800x320 |
Max.loading capacity of table |
kg |
300 |
T-slot NO./width/distance of table |
3/14/100 |
|
Spindle max.speed |
r/min |
10000 |
Main motor rated power |
kw |
3.7/5.5 |
Spindle nose taper |
BT30 |
|
Magazine capacity |
pcs |
10 |
Magazine style |
Umbrella |
|
Max.diameter of tool |
mm |
60 |
Max.length of tool |
mm |
200 |
Max. weight of tool |
kg |
5 |
Pneumatic press |
mpa |
0.6 |
N.W |
kg |
2600 |
Overall dimension |
mm |
1600x1840x2110 |
Standard:
FANUC 0i mate-MD CNC system;
3-axis precision linear guide-ways;
High precision and speed spindle unit;
Armless type magazine with 10 tools capacity;
Separated type electronic hand wheel (MPG);
RS232 interface;
Oil and water separated design;
Internal settled auto. Chip conveying units;
Interval auto-lubricating;
Full splash guard;
Tricolor alarm light;
Operation manuals (English edition).
