VERTICAL MACHINING CENTER VMC745L

Name: VERTICAL MACHINING CENTER VMC745L
Brand: TIMEWAY
SKU: 140796122
Availability: InStock

Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)

Key Specifications

Condition:

New

Brand Name:

TIMEWAY

Model Number:

VMC745L

Zhengzhou Timeway Machine Tool Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

China port

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Brand Name TIMEWAY

Model Number VMC745L

Dimension(L*W*H) 2500x2000x2450mm

Weight 3500kg

After-sales Service Provided Engineers available to service machinery overseas

VERTICAL MACHINING CENTER

Features:

1. GSK983M CNC system;

2. 3-axis linear guide-ways;

3. High precision and speed spindle unit;

4. Umbrella type magazine with 16 tools capacity;

5. Floating tools clamping system;

6. Separated type electronic hand wheel (MPG);

7. RS232 interface;

8. Oil and water separated design;

9. Interval auto-lubricating;

10. Full splash guard;

11. Tricolor alarm light.

Model	Unit	VMC745L
X-axis travel	mm	600
Y-axis travel	mm	450
Z-axis travel	mm	500
Spindle nose to table	mm	130-630
Spindle center to column guideway face	mm	485
Rapid feeding of X,Y axis	mm/min	24000
Rapid feeding of Z axis	mm/min	18000
Feeding speed	mm/min	1-5000
Table size	mm	800x450
Max. loading capacity of table	kg	550
T-slot NO./width/distance of table		3/18/160
Spindle max. speed	r/min	8000
Main motor rated power	kw	5.5/7.5
Spindle nose taper		BT40
Magazine capacity	pcs	16
Magazine style		Umbrella
Max. diameter of tool	mm	80
Max. length of tool	mm	300
Max. weight of tool	kg	6
Pneumatic press	mpa	0.6
N.W	kg	3500
Overall dimension (LxWxH)	mm	2500x2000x2450
