Home > Manufacturing & Processing Machinery > Machine Tools > Lathe > CNC Turning Center/Full Function CNC Lathe

CNC Turning Center/Full Function CNC Lathe

Name: CNC Turning Center/Full Function CNC Lathe
Brand: TIMAC
SKU: 140795954
Availability: InStock

CNC Turning Center/Full Function CNC Lathe thumbnail-1

CNC Turning Center/Full Function CNC Lathe photo-1

Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)

Key Specifications

Get Latest Price

Condition:

New

Type:

Turning Center

CNC or Not:

CNC

Contact Supplier Request Quote Chat Now

Zhengzhou Timeway Machine Tool Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

China Port.

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Condition New

Type Turning Center

CNC or Not CNC

Automatic Grade Automatic

Max. Swing Diameter 360/440mm

Place of Origin Henan, China

Brand Name TIMAC

Model Number AK-15M,AK-10,AK-15B

Voltage As request

Certification CE,ISO

After-sales Service Provided Engineers available to service machinery overseas

Specifications

1.CNC Turning Center/Full Function CNC Lathe;
2.Swing over bed:360/440mm.

Specification	Unit	AK-15M	AK-10	AK-15B
Swing over bed	mm	440	360	440
Max.turning dia.over bed	mm	300	300	320
Max.turning dia.over cross slide	mm	190	170	220
Max.turning length	mm	450	500/750/1000	450/700/950
Distance between centers	mm	600	600/800/1100	600/850/1100
Max.bar capacity	mm	52	36	52
X-axis travel	mm	180	170	190
Z-axis travel	mm	480	510/760/1010	510/760/1010
Rapid traverse(X/Z-axis)	m/min	18/20	18/20	18/20
Cutting feed(X/Z-axis)	mm/min	5000	5000	5000
Hand feed(X/Z-axis)	mm/min	1260	1260	1260
Spindle speed	rpm	50-4500	50-5000	50-4500
Spindle nose		A2-6	A2-5	A2-6
Chuck size		8″	6″	8″
Spindle front end bearing(dia)	mm	100	80	100
Spindle bore(dia)	mm	62	50	62
C-axis indexing(incrementle unit)		0.001
Number of stations		8	8	8
Indexing time	s	0.58	0.58	0.58
Tool shank size	mm	25×25	25×25	25×25
Boring bar shank dia	mm	40	40	40
Tool speed	rpm	40-4000
Main spindle motor	kw	9.0/11	7.5/11	9.0/11
X-axis servo motor	kw	1.6	1.2	1.6
Z-axis servo motor	kw	3	1.8	1.6
Tool driving motor	kw	A3/10000l
Max.travel of tailstock	mm	460	360/610/860	360/610/860
Tailstock quill dia	mm	80	80	80
Tailstock travel	mm	130	100	100
Tailstock quill taper hole		MT-4	MT-4	MT-4
Coolant capacity	L	200	120	120
Total power	kw	25	20	25
X-axis positioning accuracy	mm	0.025	0.025	0.025
X-axis repositioning accuracy	mm	0.01	0.01	0.01
X-axis reverse warp	mm	0.012	0.012	0.012
Z-axis positioning accuracy	mm	0.016	0.016	0.016
Z-axis repositioning accuracy	mm	0.007	0.007	0.007
Z-axis reverse warp	mm	0.006	0.006	0.006

FEATURES(AK-15M):

1. The CNC turning centers are semiclosed loop CNC machine tools suitable to turn various complicated shaft,sleeve and disklike workpiece such as turning of internal and external cylindrical, conical and other circumgyrationsurface as well as various metric, inch, modular and diametric pitch threads.

2. It can also be used for oil grooves and keyways broaching, end-facing, grooving and chamfering etc.

3. Besides turning applications, it can also be used to drill and mill for various complicated workpiece machining by its X/Z/C 3axis combined motion.

4. The unique construction developed using FEA techniques to provide maxmium stiffness under the heaviest cutting conditions.

5. The machining accuracy is about IT5~IT6, and the surface roughness is about Ra0.4μm for nonferrous metalcutting and Ra0.8μm for ferrous metala.

6. As universal CNC lathes, it is especially suitable for the machining of high precision workpiece, and also widely used to machining parts in batches in the fields of automabile, motorcycle, railroad, aero-craft, home-appliance, bearing, hardware, etc.

FEATURES(AK-10,AK-15B):

1. These lathes are semi-closed loop CNC machine tools suitable to turn various complicated shaft, sleeve and disk-like workpiece,such as turning of internal and external cylindrical, conical and other circumgyration surface as well as various metric,inch,modular and diametric pitch threads.

2. They can also be used for oil grooves and keyways broaching,end-facing,grooving and chamferig etc.

3. The unique construction developed using FEA techniques to provide maxmium stiffness under the heaviest cutting conditions.

4. The machining accuracy is about IT5~IT6, and the surface roughness is about Ra0.4μm for nonferrous metalcutting and Ra0.8μm for ferrous metala.

5. As universal CNC lathes, it is especially suitable for the machining of high precision workpiece, and also widely used to machining parts in batches in the fields of automabile, motorcycle, railroad, aero-craft, home-appliance, bearing, hardware, etc.
