Home > Manufacturing & Processing Machinery > Machine Tools > Lathe > CNC Flat Bed Lathe

CNC Flat Bed Lathe

Name: CNC Flat Bed Lathe
Brand: TIMAC
SKU: 140795966
Availability: InStock

Zhengzhou Timeway Machine Tool Co., Ltd.

US$ 10,000 - 25,000 MOQ: 1 Set

Key Specifications

Get Latest Price

Condition:

New

Type:

Horizontal

CNC or Not:

CNC

Contact Supplier Request Quote Chat Now

Payment & Shipping

Payment Methods:

Port of Shipment:

China port

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Condition New

Type Horizontal

CNC or Not CNC

Brand Name TIMAC

Model Number CK-400A, CK-460A, CK-500A

Specifications

1. Flad bed type CNC lathe
2. Swing dia.: 400, 460, 500mm
3. Fanuc 0i mate TD system
4. GSK980TD system
5. Spindle bore:80mm

CNC flat bed lathe

Features:

1. Longitudinal and cross feeds are effected by ball leadscrews. Driven by servo motors.
2. Either vertical or horizontal 4-station or 6-station tool post or gang tools can be selected. The post is located on precision contrite gears with a high repeated positioning accuracy.
3. Both chuck and tailstock are supplied with hydraulic or manual type.
4. The surface of the bedways is supersonic frequency hardened and precision ground with a long service life.
5. The spindle bore size is Ø 80mm. The spindle system is high in the rigidity and accuracy.

Specification	CK-400A	CK-460A		CK-500A
Over bed	Ø400mm	Ø460mm		Ø500mm
Over carriage	Ø210/Ø165mm (Gang tools)	Ø240/Ø205mm (Gang tools)		Ø280/Ø245mm (Gang tools)
Maximum turned length	750/100/1500mm
Max. turning length	620/870/1370 mm
*over gap	Ø650mm	Ø700mm		Ø740mm
*Effective length of gap	200mm
Spindle nose	D8
Spindle bore	Ø80mm
Cone hole diameter and taper of spindle hole	MT.No7
Steps of spindle speed (Manual)	Variable
Range of spindle speed	100~2000r/min
Rapid feed for Axis Z	10m/min
Rapid feed for Axis X	8 m/min
Max. travel of Axis Z	710/960/1460 mm
Max. travel of Axis X	250/330mm(Gang tools)
Min. input	0.001mm
Tool post stations	4-ways or 6-ways or gang tools
Tool cross section	25×25 mm
External diameter	Ø75mm
Taper of bore	MT.No.4		MT.No.5
Max. Traverse	130mm
X/Z motor torque	4.7/7Nm
Power of main motor	5.5KW(Extra 7.5KW)
Power of cooling pump	75W
Overall dimensions(L×W×H)	2060/2310/2790×1180×1500mm
Net weight	2100,2250,2800Kg		2200,2350,2900kg
Note: The items with “*”are only for GAP BED series

Standard:

FANUC 0i mate TD CNC system, FANUC servo feed motor, Inverter main motor, 3 jaw chuck, 4 station electric tool post, Coolant supply system, Auto. Lubrication unit, Lighting unit, General tools, Operation and maintenance manuals (English edition), etc.

Optional:

GSK980TD controller, 6 station electric toolpost, Hydraulic chuck, Hydraulic tailstock
