Flat Bed Type CNC Lathe Machine/Full Function CNC Lathe Machine CK-500B CK-560B CK-660

Zhengzhou Timeway Machine Tool Co., Ltd.
Flat Bed Type CNC Lathe Machine/Full Function CNC Lathe Machine CK-500B CK-560B CK-660 thumbnail-1
Flat Bed Type CNC Lathe Machine/Full Function CNC Lathe Machine CK-500B CK-560B CK-660 photo-1
US$ 2,000 - 35,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Type:
Horizontal
CNC or Not:
CNC
Contact Supplier Request Quote Chat Now
Payment & Shipping
Payment Methods:
Port of Shipment:
China port.
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Type Horizontal
CNC or Not CNC
Automatic Grade Automatic
Max. Swing Diameter 660mm
Place of Origin Henan, China
Brand Name TIMAC
Model Number CK-660
Voltage As request
Power(W) 11kw
Dimension(L*W*H) 2250/2500/3000/3500x1250x1580mm
Weight 3500/3800/4050/4300/4700kg
Certification CE,ISO
After-sales Service Provided Engineers available to service machinery overseas

Specifications

1.Max.swing over bed 660mm;
2.Famous brand CNC controller;
3.Variable frequency main motor

SpecificationUnitCK-500BCK-560BCK-660
Max. swing dia. over bedmm500560660
Max. swing dia. over carriagemm310330430
Center distancemm750/1000/1500/2000/3000
Max. turning lengthmm650/900/1400/1900/2900
Spindle nose A2-8D8
Spindle boremm80105
Spindel taper MT.No7113 1:20
Steps of spindle speed 2steps(Variable)4steps(Variable)
Range of spindle speedrpm

400~1600(high),

50~400(low)

27~135, 55~270,

160~805, 325~1630

Rapid feed for axis Zm/min10
Rapid feed for axis Xm/min8
Max. travel of axis Zmm720/970/1270/1970/2970
Max. travel of axis Xmm300320365
Min. inputmm0.001
Tool post stations 4/6
Tool sectionmm32×32
Tailstock sleeve diametermm75
Tailstock sleeve taper MT.No.5
Tailstock sleeve travelmm150
X/Z motor torqueNm7.5/10, 7.5/22,10/10,10/22
Main motor powerkw7.511
Cooling pump powerw90
Overall dimension(L×W×H)mm

2250/2500/3000/3500/4500

×1200×1520

2250/2500/3000/3500/4500

×1250×1580

Net weightkg2700/3000/3500/4000/46002800/3100/3700/4300/5300





Standard Accessories:

FANUC 0i mate TD CNC controller, FANUC servo feed motor, Inverter main motor, 3 jaw chuck, Electric tool post, Coolant supply system, Auto. Lubrication unit, Lighting unit, General tools, Operation and maintenance manuals (English edition), etc.



Optional Accessories:

Other brand CNC controller, 6 stations electric tool post, Hydraulic solid chuck, Hydraulic hollow chuck, Hydraulic tailstock.



Features:

1. Famous brand CNC controller

2. Variable frequency main motor;

3.Step or servo type feed diving;

4.4 or 6 stations electric or gang type tool post are available;

5. Hydraulic type chuck, hydraulic tailstock is optional.

6.Magnetic braking device is provided for spindle stopping.
