Home > Manufacturing & Processing Machinery > Machine Tools > Lathe > FANUC CNC Lathe Machine / Full Function CNC Lathe

FANUC CNC Lathe Machine / Full Function CNC Lathe

Name: FANUC CNC Lathe Machine / Full Function CNC Lathe
Brand: TIMAC
SKU: 140795786
Availability: InStock

Zhengzhou Timeway Machine Tool Co., Ltd.

FANUC CNC Lathe Machine / Full Function CNC Lathe thumbnail-1

FANUC CNC Lathe Machine / Full Function CNC Lathe photo-1

Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)

Key Specifications

Get Latest Price

Condition:

New

Type:

Horizontal

CNC or Not:

CNC

Contact Supplier Request Quote Chat Now

Payment & Shipping

Payment Methods:

Port of Shipment:

China port

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Condition New

Type Horizontal

CNC or Not CNC

Automatic Grade Automatic

Max. Swing Diameter 360-850mm(14''-33'')

Brand Name TIMAC

Model Number AK-15, AK-15B, AK-25, AK-35, AK-45

Voltage as customer's request

Power(W) 7.5/11 kw

Dimension(L*W*H) depends on different models

Weight depends on different models

Certification CE & ISO

After-sales Service Provided Engineers available to service machinery overseas

FANUC CNC Lathe Machine price , Full Function CNC Lathe

Product Description

Features :

1.These lathe are semi-closed loop CNC machine tools suitable to turn various complicated shaft, sleeve,

and disk-like workpiece, such as turning of internal and external cylindrical, concial and other

circumgryation surface as well as various metric inch, modular and diametric pitch threads.

2.They can also be used for oil grooves and keyways broaching, end facing, grooving and chamfering etc.
3.The unique construction developed using FEA techniques to provide maximum stiffness under the

heaviest cutting conditions.
4.The machining accuracy is about IT5 IT6, and the surface roughness is about Ra0.4μm for nonferrous

metal cutting and Ra0.8μm for ferrous metal's.

5.As universal CNC lathes, they are especially suitable for the machining of high precision workpieces, and

also widely used to machining parts in batches in the fields of automobile, motorcycle, railroad, aero-craft,

home appliance, bearing, hardware, etc.

Standard :

FANUC 0i TD controller, FANUC servo feed motor, Servo main motor, NSK bearings, Hydraulic solid chuck, Hydraulic solid chuck, Hydraulic tool turret, Hadraulic tailstock, Auto.lubricating unit, Cooling system, Lighting unit, General tools, Operation manual(English edition)

Optional :

Other brand CNC controllers, Hydraulic hollow chuck, Auto chip conveyor & bucket.

Parameter :

Specification	Unit	AK-10	AK-15B	AK-25	AK-35	AK-45
Max.swing over bed	mm	360	440	520	660	850
Max.turning dia.over bed	mm	300	320	420	550	800
Max.turning dia.over cross slide	mm	170	220	360	420	650
Max.turning length	mm	500/750/1000	450/700/950	530/905/1405/ 1905/2905/3905	780/1530/1890 /2890/3890	900/1400/1900/ 2900/3900
Distance between centers	mm	600/800/1100	600/850/1100	625/1000/1500/ 2000/3000/4000	890/1640/2000/ 3000/4000	1000/1500/2000/ 3000/4000
Max.bar capacity	mm	36	52	70	80	120/150
X-axis travel	mm	170	190	230	305	450
Y-axis travel	mm	510/760/1010	510/760/1010	590/965/1465/ 1965/2965/3965	855/1605/1965/ 2965/3965	950/1450/1950/ 2950/3950
Rapid traverse(X/Z-axis)	m/min	18/20		12/15	12/15	12/15
Cutting feed(X/Y-axis)	mm/min	5000
Hand feed(X/Y-axis)	mm/min	1260
Spindle speed	rpm	50-5000	50-4500	35-3500	25-2500	0-2000
Spindle nose		A2-5	A2-6	A2-8	A2-8	A2-11/A2-15
Chuck size		6"	8"	10"	12"	15"
Spindle front end bearing(dia.)	mm	80	100	130	160	200
Spindle bore(dia.)	mm	50	62	87	92	131
Number of stations		8		12
Indexing time	s	0.58		1		0.9
Tool shank size	mm	25×25				32×32
Boring bar shank dia.	mm	32	40		50	60
Motor of main spindle	kw	7.5/11	9.0/11	18.5/15	30/22	1000
Motor of X-axis servo motor	kw	1.2	1.6	1.6	3	4
Motor of Y-axis servo motor	kw	1.8	1.6	3	4	7
Max.travel of tailstock	mm	360/610/860		490/865/1365/1865/ 2865/3865	760/1500/1900/ 2900/3900	900/1400/1900/ 2900/3900
dia.Tailstock quill	mm	80		85	110	140
Travel of tailstock quill	mm	100		80	100	130
Taper hole of tailstock quill		MT-4		MT-5		MT-6
Coolant capacity	L	120		200/230/280/330	200/250/ 280/350	450
Total power	kw	20	25	30	46	130
X-axis positioning accuracy	mm	0.025
X-axis repositioning accuracy	mm	0.01
X-axis reverse warp	mm	0.012
Z-axis positioning accuracy	mm	0.016
Z-axis repositioning accuracy	mm	0.007
Z-axis reverse warp	mm	0.006
