CK Series FANUC Flat Bed Type CNC Lathe Machine For Sale
Features :
1. The nachine adopts global famous controller with RS232 interface.
2. Longitudinal and cross feeds are effected by ball leadscrews.
3.Either vertical or horizontal 4/6 station tool post or gang tools can be selected.
4. The tool post is located on precision contrite gears with a high repeated positioning accurcy.
5. Both chuck and tailstock are supplied with hydraulic or manual type.
6. The surface of the guideways is supersonic frequency hardened and precision ground with a long sercice life.
7. The spindle system is high in the rigidity and accuracy.
8. An inverter is used to realize variable speed.
Standard accessories:
FANUC 0i mate controller, FANUC servo feed motor, inverter main motor, NSK bearings, 3 jaw chuck,
4station electric tool post, manual tailstock, automatic lubricatiing unit, cooling system, lighting unit,
general tools, operation manaual (English edition).
Optional accessories:
Other brand controllers, 6 station electric tool post, gang type tool post, hydraulic solid chuck,
hydraulic hollow chuck, hydraulic tailstock
Parameter accessories:
Model |
CK-300S |
CK-360S |
CK-400S |
CK-400A |
CK-460A |
CK-500B |
CK-660 |
Max. swing over bed |
300mm |
360mm |
400mm |
460mm |
500mm |
660mm |
|
Max. swing over slide |
135/100mm |
180/100 mm |
240/150mm |
210/165 mm |
250/205 mm |
310mm |
430mm |
Max. cross travel (X) |
180/270mm |
235/300mm |
250/330mm |
300mm |
365mm |
||
Max. length of workpiece |
500mm |
500/750/ |
750/1000/150mm |
750/1000/1500/2000/3000mm |
|||
Rapid feed for Axis X |
8m/min |
||||||
Rapid feed for Axis Z |
10m/min |
||||||
Range of spindle speeds |
200-3500rpm |
200-1800rpm |
1000-2000rpm |
200-1600rpm(high) 25-250rpm(low) |
20-150,150-433 433-1300rpm |
||
Spindle bore |
38mm |
40mm |
52mm |
80mm |
80mm |
105mm |
|
Taper of spindle bore |
MT NO.5 |
MT NO.6 |
MT NO.7 |
1:20 |
|||
Number of tools |
4 or 6 or gang tools |
||||||
Size of tool shank |
16×16mm |
20×20mm |
25×25mm |
32×32mm |
|||
Min input |
0.001mm |
||||||
Repeatability (X/Z) |
0.0075/0.01mm |
||||||
Power of main motor |
3kw |
3.7kw |
5.5kw |
7.5kw |
11kw |
||
Power of coolant pump |
75w |
||||||
Overall dimension (L×W×H) |
1500×945× |
1870/2120/2370×1200×1415 |
2060/2310/2790× |
2250/2500/3000/ 3500/4500×1200 ×1520mmm |
2250/2500/3000/3500 ×1250× 1580mm |
||
Net weight |
950kg |
1700/2000 /2200kg |
1800/2100/2300kg |
2380/2580/3050 kg |
3000/3300/3550/ 3800/4200kg |
3500/3800/4050 /4300/4700kg |
|
