CPB- Series CNC Hydraulic Press Brake

CPB- Series CNC Hydraulic Press Brake thumbnail-1
CPB- Series CNC Hydraulic Press Brake photo-1
Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Henan, China
Brand Name:
TIMAC
Model Number:
CPB- Series
Contact Supplier Request Quote Chat Now
Zhengzhou Timeway Machine Tool Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
China Port
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Henan, China
Brand Name TIMAC
Model Number CPB- Series
Condition New

Specifications

1.CNC Hydraulic Press Brake
2.Nominal pressure:40-400ton
3.Length:2200-7000mm
4.Deflection compensation
5.Mechanical stop

CNC Hydraulic Press Brake Machine



Features:

1. Steel-welded construction, vibration to eliminate stress, with high strength and good rigidity.

2. Hydraulic top-strive, steadiness and reliability.

3. Mechanical stop, steel torsion bar to maintain synchronization, high precision.

4. Motorized-adjusting device of backgauge and rams stroke, fine adjusting by handwheel, numerical display.

5. Deflection compensation unit installed on the top die. Manual crowned bottom die holder is adopted for the machine above 250ton, length: 4000mm.

6. Travel limit protection, and full machine guarding with safety interloocker.



Specification

Nominal pressure (KN)

Length of working table (mm)

Depth of throat (mm)

Ram stroke (mm)

Number of stroke (m/min-1)

Motor power (kw)

CPB-40/2200

400

2200

200

100

11

4

CPB-40/2500

400

2500

200

100

11

4

CPB-63/2500

630

2500

250

100

10

5.5

CPB-63/3200

630

3200

250

100

10

5.5

CPB-80/3200

800

3200

320

150

8

7.5

CPB-80/4000

800

4000

320

150

8

7.5

CPB-100/3200

1000

3200

320

150

8

7.5

CPB-100/4000

1000

4000

320

150

8

7.5

CPB-125/3200

1250

3200

320

150

8

7.5

CPB-125/4000

1250

4000

320

150

8

7.5

CPB-160/3200

1600

3200

400

180

8

11

CPB-160/4000

1600

4000

400

180

8

11

CPB-160/6000

1600

6000

400

180

7

15

CPB-200/3200

2000

3200

400

200

7

15

CPB-200/4000

2000

4000

400

200

7

15

CPB-200/6000

2000

6000

400

200

7

15

CPB-250/6000

2500

6000

400

250

7

18.5

CPB-300/6000

3000

6000

400

250

7

22

CPB-300/7000

3000

7000

400

250

7

22

CPB-400/7000

4000

7000

400

250

7

30
