NC Hydraulic Three Roller Symmetrical (Metal Sheet) Plate Rolling Machine
US$ 15,000 - 50,000
MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Brand Name:
TIMAC
Model Number:
HTR-30*2500
Payment & Shipping
Payment Methods:
Port of Shipment:
China Port
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Manual or Mechanical or Hydraulic Three Roller Asymmetrical Steel Metal Plate Rolling MachineUS$ 16,000 - 50,000MOQ: 1 Set -
Mechanical Three Roller Symmetrical Plate Bending Rolling MachineUS$ 10,000 - 100,000MOQ: 1 Set
-
High Efficiency Hydraulic Full Automatic Two Rollers Rolling MachineUS$ 10,000 - 80,000MOQ: 1 Set
-
Semi-automatic Pipe Bending Machine (SB-38NCB)US$ 5,000 - 10,000MOQ: 1 Set
-
NC Arc Down-adjusting 3-roller Rolling MachineUS$ 5,000 - 30,000MOQ: 1 Set
Condition
New
Brand Name
TIMAC
Model Number
HTR-30*2500
Machine Type
Other, Coiling bending machine, Roll forming machine, Roller-bending machine
Raw Material
Sheet / Plate Rolling
Material / Metal Processed
Other, All kinds of steel sheet
Power
Hydraulic
Automation
Other, Semi-automatic
Extra Services
Other, Rolling cone workpiece
Certification
CE
After-sales Service Provided
Engineers available to service machinery overseas
NC Hydraulic Three Roller Symmetrical Plate/Metal Sheet
Bending/Rolling Machine
HTR-30*2500
Main Outlook
Product Description
Features:
The construction of this machine is in the form of three roller symmetry. The top roller, in the central symmetry position over the two bottom rollers, does vertical motion up and down through screw, nut and worm transmission. Decelerator gears bottom rollers providing torsion moment for coiling sheet metal. The construction of the machine is compact and the operation and maintenance is convenient.
Specifications List
Technical Parameters
| Model | Max. rolling thickness (mm) | Plate width (mm) | Diameter of upper roller (mm) | Main motor power (kw) |
| HTR-25*2000 | 25 | 2000 | 320 | 15 |
| HTR-25*2500 | 25 | 2500 | 380 | 15 |
| HTR-30*2000 | 30 | 2000 | 360 | 15 |
| HTR-30*2500 | 30 | 2500 | 420 | 22 |
| HTR-30*3000 | 30 | 3000 | 450 | 30 |
| HTR-40*3000 | 40 | 3000 | 540 | 37 |
| HTR-50*3000 | 50 | 3000 | 580 | 45 |
| HTR-60*3000 | 60 | 3000 | 660 | 55 |
| HTR-70*3000 | 70 | 3000 | 710 | 55 |
| HTR-80*3000 | 80 | 3000 | 770 | 75 |
| HTR-90*3000 | 90 | 3000 | 820 | 75 |
| HTR-100*3000 | 100 | 3000 | 860 | 90 |
| HTR-110*3000 | 110 | 3000 | 900 | 90 |
| HTR-120*3000 | 120 | 3000 | 950 | 110 |
