Specifications
waste dump Truck95hp diesel engine
3300wheelbase
Loading capacity:3T
factory direct sale
DFAC Garbage Truck Refuse Truck Waste Truck
This truck is used to collect, transship and transport wastes. It is the new environmental sanitation truck for avoiding secondary pollution.This kind of garbage truck is made of the chassis, cargo box, open-door structure, lifting structure, and electro-hydraulic control system.
It is mainly used to transporting the daily wastes, but sometimes it is also could be used to transport bulk construction materials, like ash, sand, stone, soil, etc, and carry ore and coal in mines.
Simple functional introduction about the sealed garbage truck:
The bucket could be separated with the truck body, and the truck could work with several buckets for circulation. It saves time and improves the truck transporting ability
Item |
unit |
parameter |
||
Vehicle model |
|
CLW5060ZLJ3 |
||
Chassis model |
|
EQ1060TJ20D3 |
||
Overall dimension |
mm |
5500×2000×2230 |
||
Tank dimension |
3600×1750×600 |
|||
|
G W |
kg
|
6010 |
|
|
Rate loading |
2380 |
||
Curb weight |
3500 |
|||
Wheel base |
mm |
3300 |
||
F/R suspension |
1032 /1168 |
|||
track front/rear |
1506/1466 |
|||
Approach/departure angle |
|
19/12 |
||
|
Engine type |
YC4F90-30 |
||
Exhaust/hp |
ml/kw |
2656/66 |
||
Max speed |
km/h |
90 |
||
Emission standards |
GB3847-2005,GB17691-2005 |
|||
Tire specification |
7.00-16,6.50-16,7.00R16,6.50R16 |
Traction system |
4×2 |
|
Number of axles |
2 |
Electric system |
24v |
|
Operation control system |
Electrically hydraulic control |
Allowable passengers in cab |
2 |
|
Equipment |
Equipped with hermetic dustbin, hydraulic system and operating system |
|||
The picture and parameter mentioned above is only for reference. The specific product can be produced according to your order.
