New Foton Garbage Truck on Sale

Name: New Foton Garbage Truck on Sale
Brand: Foton
SKU: 140714894
Availability: InStock

Shanghai Evangel Industrial Co., Ltd.

5Yrs

US$ 50,000 - 80,000 MOQ: 1 Set

Key Specifications

Condition:

New

Drive Wheel:

4x2

Type:

Compactor

Payment & Shipping

Payment Methods:

Port of Shipment:

Shanghai port

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Drive Wheel 4x2

Type Compactor

Transmission Type Manual

Emission Standard Euro 3

Fuel Type Diesel

Engine Capacity EURO 3

Size 8890*2495*3100

Gross Vehicle Weight 10000

Place of Origin Zhejiang, China

Brand Name Foton

Model Number ZQZ5164ZYS

Certification ISO CE

After-sales Service Provided Engineers available to service machinery overseas

Product Description

garbage compactor truck
dustbin can lift by the hydraulic system
the garbage box is a hermetic box
large capactiy easy con

(QUALITY PARAMETERS):
VEHICLE QUALITY (kg)	10000		TOTAL MASS (kg)	16000
RATED LOAD MASS (kg)	5805		BOUNDARY DIMENSIONS(mm)	8890×2495×3100
(CHASSIS PARAMETERS):
CHASSIS MODEL		DFL1160BX4	TYRE MODEL	10.00R20/9.00R20
WHEELBASE (mm)		4500	TREAD(front/rear)mm	1880/1860
FRONT SUSPENSION (mm)		1430	REAR SUSPENSION(mm)	2660
APPROACH/DEPARTUREANGLE(°)		20/17	MIN.AROUND CLEARANCE (mm)	250
(ENGINE PARAMETERS):
MODELS	ISDe 210 40		MANUFACTURE	Dongfeng
MAX.POWER(kw)	155		MAX.TORQUE (N.m)	800
BORE/STROKE(mm)	6-107×124		DISPLACEMENT(ml)	6700
FUEL TYPE	diesel
(EQUIPMENT PARAMETERS):
RATED LOAD CAPACITY(m³)	14		FILL CAPACITY(m³)	14
HYDRAULIC PUMP MODEL	CBG2080/ 2032-BFPL		HYDRAULIC VALVE MODEL	Q130/A5-F7SN,(GALTECH)
WATER PUMP MODEL	/		MOTOR MODEL	/
(PERFORMANCE AND OTHER PARAMETERS):
MAX.SPEED(km/h)	90		MAX.GRADEBILITY(°)	30
MAX.BRAKINGDISTANCE(m)	≤10		MIN.TURNING CIRCLE DIA.(m)	16
NO. of LEAD SPRING(FRONT/REAR)	8/10+8,7/9+6		AXES	2
