Specifications
1.UL approved LiFePO4 cell;2.System scalable up to 450V;
2.Easy to install,debug and maintain;
3.Qualified BMS for EV/HEV
O'CELL can offer a scalable, modular approach, with configurations in excess of 450 volts and 1,000 Ah in custom solutions. The modules are packaged in standard lead acid BCI format sizes suited for a huge variety of applications.
Specification
No. |
Item |
Specification |
Remark |
1 |
Battery module |
IFM18-700E1(19.2V70Ah) |
|
2 |
Assemble method |
22S1P |
|
3 |
Nominal voltage |
422.4V |
|
4 |
Nominal capacity |
70Ah |
|
5 |
Whole Energy |
29.6KWh |
|
6 |
Voltage Range |
330~481.8V |
adjustable |
7 |
Charge Current |
≤35A |
|
8 |
Discharge Current |
≤100A |
|
9 |
Peak Discharge Current |
≤200A(10S) |
|
10 |
Approx. Weight |
<340Kg |
|
11 |
Approx. Resistance |
<480mΩ |
|
12 |
Reference Dimension(L*W*H) |
Depend on its configuration |
|
13 |
Temperature Range |
charge:0~50°C |
|
discharge:-10~55°C |
|
||
14 |
Storage Temperature |
-10~45°C |
|
15 |
Over Voltage Warning |
514.8V |
adjustable |
16 |
Over Voltage Alarm |
528.0V |
adjustable |
17 |
Under Voltage Warning |
369.6V |
adjustable |
18 |
Under Voltage Alarm |
303.6V |
adjustable |
19 |
Over Temperature Warning |
60°C |
adjustable |
20 |
Over Temperature Alarm |
65°C |
adjustable |
21 |
Regeneration |
Depend on motor controller |
|
Note:
1. Each battery module has one slave BMS circuitry inside;
2. Master BMS circuitry(we named BMU) collect all information from each battery module through
RS485, then decide to cut-off the contactor or not;
3. We strongly recommend customer to use two contactors (one for charge and another for
discharge) at least in the battery system.
BMS:
O’CELL BMS consists of Master BMS Circuitry (we named “BMU”), Slave BMS Circuitry (we integrate it into our battery module) and contactor.
Besides the basic functions such as over charge/ discharge, over current, short circuit, over
temperature and balancing, Our BMS owns the following features,
1. Master-Slave architecture makes the system flexible;
2. Two level warning makes maintenance easier;
3. CAN2.0 and industrial level electronic components make system reliable;
4. Contactor makes high rate charge & discharge feasible;
5. Periodic insulation measurement makes personnel safety possible;
6. Host can control the system easily;
1. Modular design makes the system installation, maintenance easier;
2. Battery modules can be connected in series or parallel to make the system more flexible;
3. IP56 dust and water proof design suit for severe circumstance;
4. Dual LED indicator makes the battery module status easy to know;
5. High accuracy SOC calculation
BMU Photo
Monitoring Software (Need USB-CAN Adapter)
