Place of Origin Guangdong, China
Brand Name UK imported
Model Number GNRP
Output Type AC Three Phase
Speed 1500rpm or 1800rpm
Frequency 50Hz or 60Hz
Rated Power 7 kw to 1000kw
Rated Voltage 220V/380V, 230V/400V, 240V/415V
Rated Current 13A To 1800A

Specifications

Power Generator Motor
-Low Fuel Consumption
-Globally Servic
-CE

    Power Generator Motor



UK imported  diesel generator set have earned a reputation for ease of service along with low costs of maintenance and repair and all  Power part products carry an unequivocal 12-months warranty from date of purchase.



 Power Generator Motor

Genset Model Prime Power Standby Power Engine Fuel Consumption Cylinder No. Displacement Bore X Stroke
KW KVA KW KVA (g/kwh)  (L ) (mm)
GNRP10 7 9 8 10 403D-11 ≤252 3 1.131 77*81
GNRP15 10 13 12 15 403D-15 ≤264 3 1.496 84*94
GNRP23 16 20 18 23 404D-22 ≤243 4 2.216 84*100
GNRP33 24 30 26 33 1103A-33G ≤210 3 3.3 105*127
GNRP50 36 45 40 50 1103A-33TG1 ≤212 3 3.3 105*127
GNRP65 48 60 52 65 1103A-33TG2 ≤211 3 3.3 105*127
GNRP73 52 65 58 73 1104A-44TG1 ≤207 4 4.4 105*127
GNRP88 64 80 70 88 1104A-44TG2 ≤213 4 4.4 105*127
GNRP103 75 94 82 103 1006TG1A ≤210 6 5.99 100*127
GNRP150 110 138 120 150 1006TAG ≤205 6 5.99 100*127
GNRP165 120 150 132 165 1006TAG2 ≤205 6 5.99 100*127
GNRP225E 165 206 180 225 1306C-E87TAG3 ≤220 6 8.7 117*136
GNRP250E 180 225 200 250 1306C-E87TAG4 ≤219 6 8.7 117*136
GNRP259E 188 235 207 259 1306C-E87TAG5 ≤221 6 8.7 117*136
GNRP275E 200 250 220 275 1306C-E87TAG6 ≤223 6 8.7 117*136
GNRP344E 250 313 275 344 2206C-E13TAG2 ≤201 6 14.6 137*165
GNRP388E 280 350 310 388 2206C-E13TAG2 ≤198 6 14.6 137*165
GNRP450E 320 400 360 450 2206C-E13TAG3 ≤201 6 14.6 137*165
GNRP500E 360 450 400 500 2506C-E15TAG1 ≤216 6 15 137*171
GNRP550E 400 500 440 550 2506C-E15TAG2 ≤211 6 15 137*171
GNRP625E 450 563 500 625 2806A-E18TAG1A ≤196 6 18.13 145*183
GNRP700E 508 635 560 700 2806A-E18TAG2 ≤203 6 18.13 145*183
GNRP800 580 725 640 800 4006-23TAG2A ≤199 6 22.921 160*190
GNRP900 640 800 720 900 4006-23TAG3A ≤200 6 22.921 160*190
GNRP1000 720 900 800 1000 4008-TAG1A ≤206 8 30.561 160*190
GNRP1125 818 1022 900 1125 4008-TAG2A ≤208 8 30.561 160*190
GNRP1375 1000 1250 1100 1375 4012-46TWG2A ≤212 12 45.482 160*190





  Genset Features:

1. Genuine UK UK imported  industrial diesel engine

2. Radiator 40°C max, fans are driven by belt, with safety guard

3. Genuine stamford. Leroy somer, marathonm, engga alternator

4. Choice of manual/auto and AMF control panels and protection systems

5. Digital auto-start panel

6. Anti Vibration Suspension Absorber

7. Dry type air filter, fuel filter, oil filter

8. 10-hour operation base tank

9.Mould case circuit breaker

10. 24V DC start motor and storage battery

11. 24V charge alternator

12. 24V batteries, rack and cable

13. Rippl;e flex echaust pipe, exhaust siphon, flange, and muffler

14.   Comply with ISO and CE standards

15. All generator sets are gone through rigorous testing before beging released to the market place, including 50% load, 75% load, 100% load and all protection function(over speed stop, high water temperature, low oil pressure, battery charging fail, emergency stop)



 Engine Features:

1. Genuine UP industrial diesel engine

2. Multi-cylinder in-line or veer engine, 4-stroke, direct injection

3. Naturally aspirated, turbocharged, water cooled or turbocharged with air intercooler

4. Machinery or electronic governing

5. Fuel injection pump

6. Electric motor starting system

7. Forged steel crankshaft, cast iron cylinder and replaceable wet type cylinder liner

8. Low discharge, and low fuel consumption

9. Installed conveniently and maintain easily

 Power Generator Motor

Alternator Features:

1. World famous brand AC alternator: Leroy Somer, Stamford, Marathon, ENGGA

2. Brushless, 4 poles, rotation magnet

3. IP21-23(NEMA1) enclose is standard for all industrial alternators

4. H class insulation system

5. AVR self-regulated, voltage regulation rate: ≤±1%

6. Simple installation and maintenance with easy access to terminals, rotating diodes and coupling bolts

7. Wide range of flange adaptors and single bearing disc coupling

8. Radio interference restraining accords with the stipulation of VDE0875-N and ISO8528

9. Moisture proof, sand-proof, dustproof, salt-proof and vibration-proof

 Power Generator Motor



Control system with ATS :

Auto start when power goes out

Auto stop when power comes back on

Worldwide technical support with programmable software download

Full online documentation

Trouble shooting symbols to assist owner on concerns with the generator

Safety shutdown feature to protect the engine and generator from damage

Totally digital with few points of contact to the engine to increase reliability

Exercise features and daily start and stop programmable

 Power Generator MotorPower Generator Motor

Silent /Soundproof Box:

1. Excellent ventilation

2. Oil tank mounted on base frame for 12 Hours working

3. Highly Corrosion Resistant construction

4. Excellent Access for Maintenance

5. Security and Safety

6. 1m<80DBA / 7m<70DBA



Power Generator Motor



Power Generator Motor
