19200bps Data Radio Support 4FSK

 FC-302 is a synthesized 5-watt FM transceiver module, which is designed for data transportation and voice communication. For the voice communication, it can support selected pre-emphasis, squelch and audio amplifier. Two-point modulation with good low-frequency response is applied in the radio that makes it a competitive choice for 9600-baud rate data application. Compact dimension and wide range DC support make it flexible to use.

Features

• CE, FCC& AS/NZS 4295: 2004 certified
• Programmable 16 channels with Dip-Switch
• Configurable power save feature
• Optional external channel change
• FSK, FFSK& GMSK modem option
• Frequency step 5 KHz/6.25KHz
• CTCSS/DCS
• Support maximum RF data rate: 19200bps
• Fast start-up time: 5ms
• SQ programmable via PC
• Pocsag Modulation support
• PC programmable & Software tune & Calibration

Applications
•  Industrial telemetry & wireless remote control
•  Gas and oil flow monitoring
•  Electricity, water and gas utilities
•  Earthquake, weather, environmental protection and urban lighting control
•  Vehicle tracking and asset tracking systems
•  Water monitoring, wastewater management and irrigation control
•  Railway, police, army automation system
•  Aerial defense and fire alarm system
•  Wireless Paging system

Technical Specifications

GENERAL
 Working Frequency:  450MHz~490MHz
Channel Spacing: 12.5KHz /25KHz (Programmable)
Number of Channels: 16
Working Voltage: 9V-18V DC (Extreme)
Operating Temperature:  -30℃~+65℃
Storage Temperature:  -40℃~+80℃
Lock Time:<5ms
Frequency Error: <2.5ppm

RECEIVER
RX Sensitivity <-119dBm
         Extreme <-115dBm

Intermodulation >65dB
Audio Output Power 0.5W @ 8Ω
RX Audio Distortion <5%

TRANSMITTER

RF Power                             1~5W(Programmable)
Frequency Deviation          <5KHz(25KHz)
                                               <2.5KHz(12.5KHz)
                                               Subsonic 0.5 KHz
Audio Response                300Hz~3KHz +1/-3dB (25KHz)
                                               300Hz~2.55KHz +1/-3dB(12.5KHz)
Adj. Channel Power          <-70dBc (25 KHz)
                                              <-65dBc(12.5KHz)
TX SNR                                >45dB(25KHz) >40dB(12.5KHz)

ACCESSORIES
BNC Antenna
PC Programming Software
Cable (Serial)
Extender for Service and  Alignment
