FC-302 is a synthesized 5-watt FM transceiver module, which is designed for data transportation and voice communication. For the voice communication, it can support selected pre-emphasis, squelch and audio amplifier. Two-point modulation with good low-frequency response is applied in the radio that makes it a competitive choice for 1200-19200bps data rateapplication. Compact dimension and wide range DC support make it flexible to use.
• CE, FCC&AS/NZS 4295: 2004 certified
• Programmable 16 channels with Dip-Switch
• Configurable power saving feature
• Optional external channel change
• FSK, 4FSK& GMSK modem option
• Frequency step 5 KHz/6.25KHz
• CTCSS/DCS
• Support maximum RF data rate: 19200bps
• Fast start-up time: 5ms
• SQ programmable via PC
• Pocsag Modulation support
• PC programmable & Software tune & Calibration
Applications
• Industrial telemetry & wireless remote control
• Gas and oil flow monitoring
• Electricity, water and gas utilities
• Earthquake, weather, environmental protection and urban lighting control
• Vehicle tracking and asset tracking systems
• Water monitoring, wastewater management and irrigation control
• Railway, police, army automation system
• Aerial defense and fire alarm system
• Wireless Paging system
Technical Specifications
GENERAL
Ÿ Working Frequency 450MHz~490MHz
Ÿ Channel Spacing 12.5KHz /25KHz (Programmable)
Ÿ Number of Channels 16
Ÿ Working Voltage 9V-18V DC (Extreme)
Ÿ Operating Temperature -30℃~+65℃
Ÿ Storage Temperature -40℃~+80℃
Ÿ Lock Time <5ms
Ÿ Frequency Error <2.5ppm
Receiver
Ÿ RX Sensitivity <-119dBm
Extreme <-115dBm
Ÿ Intermodulation >65dB
Ÿ Audio Output Power 0.5W @ 8Ω
Ÿ RX Audio Distortion <5%
Transmiter
- RF Power 1~5W(Programmable)
- Frequency Deviation <5KHz(25KHz)
- <2.5KHz(12.5KHz)
- Subsonic 0.5 KHz
- Audio Response 300Hz~3KHz +1/-3dB (25KHz)
- 300Hz~2.55KHz +1/-3dB(12.5KHz)
- Adj. Channel Power <-70dBc (25 KHz)
- <-65dBc(12.5KHz)
- TX SNR >45dB(25KHz) >40dB(12.5KHz)
Accessories
- BNC Antenna
- PC Programming Software
- Cable (Serial)
- Extender for Service and Alignment
