Specifications
CE, FCC& AS/NZS 4295: 2004 certified; CTCSS/DCS; Fast lock time: 5ms
FC-302 is a synthesized 5-watt FM transceiver module, which is designed for data transportation and voice communication. For the voice communication, it can support selected pre-emphasis, squelch and audio amplifier. Two-point modulation with good low-frequency response is applied in the radio that makes it a competitive choice for 1200-19200bps data rate application. Compact dimension and wide range DC support make it flexible to use.
Key points
• CE, FCC& AS/NZS 4295: 2004 certified
• Programmable 16 channels with Dip-Switch
• Configurable power saving feature
• Optional external channel change
• FSK, FFSK& GMSK modem option
• Frequency step 5 KHz/6.25KHz
• CTCSS/DCS
• Support maximum RF data rate: 19200bps
• Fast start-up time: 5ms
• SQ programmable via PC
• Pocsag Modulation support
Applications
• Industrial telemetry & wireless remote control
• Gas and oil flow monitoring
• Electricity, water and gas utilities
• Earthquake, weather, environmental protection and
urban lighting control
• Vehicle tracking and asset tracking systems
• Water monitoring, wastewater management and irrigation control
• Railway, police, army automation system
• Aerial defense and fire alarm system
• Wireless Paging system
Technical Specifications
GENERAL
Working Frequency: 450MHz~490MHz
Channel Spacing: 12.5KHz /25KHz (Programmable)
Number of Channels: 16
Working Voltage: 9V-18V DC (Extreme)
Operating Temperature: -30℃~+65℃
Storage Temperature: -40℃~+80℃
Lock Time:<5ms
Frequency Error: <2.5ppm
RECEIVER
RX Sensitivity <-119dBm
Extreme <-115dBm
Intermodulation >65dB
Audio Output Power 0.5W @ 8Ω
RX Audio Distortion <5%
TRANSMITTER
RF Power 1~5W(Programmable)
Frequency Deviation <5KHz(25KHz)
<2.5KHz(12.5KHz)
Subsonic 0.5 KHz
Audio Response 300Hz~3KHz +1/-3dB (25KHz)
300Hz~2.55KHz +1/-3dB(12.5KHz)
Adj. Channel Power <-70dBc (25 KHz)
<-65dBc(12.5KHz)
TX SNR >45dB(25KHz) >40dB(12.5KHz)
ACCESSORIES
BNC Antenna
PC Programming Software
Cable (Serial)
Extender for Service and Alignment
Packaging: Carton
Shipping: DHL, UPS, Fedex,TNT
