VHF/UHF 5W With 9600bps Data Radio
Negotiable
MOQ: 5 Pieces (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
Friendcom
Model Number:
FC-301D
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Two-way Data Link RadioNegotiableMOQ: 100 Pieces -
Friendcom Data and Voice Radio UHF With CE CERTIFIEDNegotiableMOQ: 2 Sets
-
Data and Voice Transceiver of FC-301D ModemNegotiableMOQ: 2 Pieces
-
433 MHz Data RadioNegotiableMOQ: 2 Pieces
-
High Speed for Long Distance Data RadioNegotiableMOQ: 2 Pieces
Place of Origin
Guangdong, China
Brand Name
Friendcom
Model Number
FC-301D
Specifications
UHF and VHF modelare PLL and offer one to five watts of power with 16 channel capability.1200 to 9600 baud rates GMSK&FSK
FC-301/D Data Link Radio
Product Information
The FC-301/D Series of RF Link Modules utilize the latest technology in its design and manufacturing. Both the UHF and VHF models are PLL (Phase Lock Loop Synthesizer) / microprocessor controlled, and offer one to five watts of power with 16 channel capability. Multiple functions including AC audio coupling, 1200 to 9600 baud rates GMSK and FSK modulation capability are standard in these fully programmable wide bandwidth RF Link Module units.
- Features:
- Two-point modulation for good low frequency response used in radio makes it good choice to work with 9,600bps baud data
- Compact size and multi-voltage DC connection capability gives module flexibility in use
- Synthesized frequency tuning
- Operates from 9 to 15V DC
- 1 to 5W RF power programmable
- 16-channel frequency programmable
- 12.5/25kHz channel spacing optional
- Frequency step 5 or 6.25kHz compatible
- PC programming via software
- Designed for data as well as voice (with selectable pre-emphasis, squelch and audio amplifier
- Certification: CE and FCC
- Specification:
- Frequency band
- UHF: 400 to 470MHz
- VHF: 136 to 174MHz
- Channel spacing: 12.5 or 25kHz (optional)
- RF output power: 1 to 5W programmable
- Modulation types: 16K0F3E and 8K5F3E
- Intermediate frequency: 455kHz and 45.1MHz
- Number of channels: 16
- Frequency stability: ±2.5ppm
- RX sensitivity (12dB SINAD):
- UHF: <-117dBm
- VHF: <-118dBm
- Operation rating: intermittent 5:5:90 (TX:RX:standby)
- Power supply: 2.5V DC nominal voltage
- TX current (5W RF power, 12.5V): <1.5A
- Standby (muted) current: ≤40mA
- Antenna impedance: 50Ω
- Antenna port: BNC connector and female
- Operating temperature range: from -30 to 65°C
- Dimension: 120 x 60 x 20mm
- Weight: 200g
- Frequency band
- Applications:
- Industrial telemetry and wireless remote control
- Gas and oil flow monitoring
- Electricity, water and gas utilities
- Earthquake, weather, environmental protection and urban lighting control
- Vehicle tracking and asset tracking systems
- Water monitoring, waste water management and irrigation control
- Railway, police, army automation system
- Aerial defense and fire alarm system
- Wireless paging system
