Specifications
1,13.56mhz usb key reader2.Frequency:13.56MHz
3.Support ISO14443A or ISO15693
4.Size:74X19X6mm
5.Interface:USB
13.56mhz usb key rfid reader with SDK, demo software, user manual and source code can provide free card for testing
Product description
CF-RH360 series desktop readers are smart modules without touching based on international
standard agreement ISO14443A/B,ISO15693
CF-RH360 are equipped with high capability chip, processor, security and electric monitor. The
reader can communicate with PC by means of interface.
CF-RH360 are of high capability, anti-jamming, small size and good quality, which brings more
convenience.
Product mode explanation
Model |
standard |
interface |
color |
CF-RH361 |
IS014443A |
U(USB) |
W(white) |
CF-RH362 |
ISO15693 |
U(USB) |
W(white) |
CF-RH363 |
ISO/IEC14443A/B,ISO15693 |
U(USB) |
W(white) |
Parameter
Name |
HF Reader&writer |
Dimension |
74X19X6mm |
Standard |
ISO 14443A/B/ISO15693 |
Support |
MF One S70; MF One UltraLight; MF One S50,I-code2 |
Frequency |
13.56MHz |
speed |
106kbit/s |
Baud Rate |
9600 bit/s |
Power Supply |
+5V DC |
Consumed Current |
< 80Ma |
Operating Distance |
50--70mm |
Interface |
USB |
Status Indication |
1pcLED |
Service Temperature |
-10°C ~ +70°C |
Store Temperature |
-20°C ~ +80°C |
Product application
Widely used in access control, attendance, conference attendance, medical insurance, hotels
highways, petrol stations, parking, public transportation, such as toll collection system.
Other support
1.This reader can support ISO14443A/B,ISO15693 protocol card read and write function,it can work under Linux,Windows operation system,you can directly connect computer through USB interface.
2.we can provide complete SDK,demo software,source code and user manual to help you do application software developing.
3.We can also make it into 125khz (support EM card read-only) and 13.56mhz (MF card read-only),besides,we can also provide OEM service.
4.More exact product information, please come to below link to check:
/productdetails.aspx?pid=368
Product picture
