Specifications
1.environment-friendly2.low operating cost
3.stable performance
4germany Y-tong technology
German technology Dongyue brand autoclave aerated concrete blocks production
(35 lines abroad in 6 countries,14 lines in India)
Technology transfer cooperation with Ge
1.Our unique advantage:
(1) Our company is famous and Specializing in producing AAC block machinery about 10 years,we have 14 sets AAC plant in Indonesia,14 sets in India.5 sets in Vietnam,2 sets in Burma,so we have much experience to set up AAC production line in worldwide.
we also have office in india and indonesia,Vietnam to supply the after service and spare parts.
(2) We are the top leader in China on manufacturing the Autoclaved Aerated Concrete Line (AAC). we have set up about 200 AAC block production line in China domestc market.
(3) Wer have cooperated with Germany company AAC CONCEPT GMBH about technique transfer,Our aac block machine inherits germany technology.
(4) We have our company own AAC production line,so clients can send their engineer or technical worker to be trained in our aac plant workshop.
2.AAC block
(1)light weight
Areated concrete density is usually 400-700kg/m3,(according the market in produce ),same as 1/3 of clay brick and 1/5 common concrete.So use the Light brick can reduce the weight of the build more,and also reduce the beam of roof and pillar press best.then you can see,it can save the material and cost,it also fighting shaking.
(2) keeping temperature
It has many are porous,the delivery hearting coefficient is 0.9-0.22W/(mk),the same as 1/4 or
1/5 of clay brick,so it is best materials now in the world.There are many kinds material,have
lowest waste.
(3)High Strength
High pressure steam-curing autoclaving process gives AAC unmatchable strength to weight ratio, higher than even M150 concrete and far exceeds the Indian Building code requirements
(4)Cost saving
Being lightweight AAC drastically reduces the dead weight of building, resulting into reduction in steel (up to 27%) and cement (up to 20%) structural cost saving.Being 8 times the size of a clay brick, AAC wall construction involves 1/3 the joints, thus an overall mortar saving up to 66%
3.Cement lime fly ash style aerated block raw material proportion
name | unit | Cement lime fly ash |
flash | % | 65-70 |
cement | % | 6-15 |
lime | % | 18-25 |
gypsum | % | 3-5 |
Aluminum powder paste(600kg/m3) | 1/10000 | 8 |
Water & material rate | 0.60-0.65 | |
Casting system | OC | 36-40 |
Aluminum mixing time | S | 30-40 |
4.Cement lime Sand style aerated block raw material proportion
Name | Unit | Cement Lime Sand |
Sand | % | 55-65 |
Cement | % | 10-20 |
Lime | % | 20-30 |
Gypsum | % | 2-3 |
Aluminum powder paste(600kg/m3) | 1/10000 | 8 |
Water & material rate | 0.65-0.75 | |
Casting system | OC | 35-38 |
Aluminum mixing time | S | 30-40 |
5.AAC block Market Analysis
AAC is becoming more and more popular around the world, from western countries and then to developing countries. Below Properties make AAC have unmatchable property, especially for high buildings:
1) Extreme Light Weight
2) Large Variety of Sizes
3) High Fire Resistant
4) Excellent Thermal Insulation
5) Great Sound Insulation
6) Moisture Protection
7) Termite Resistant
8) High Workability and Easy Processing
Video link:
Video introduction of fully automatic AAC working processes : /watch?v=lnhb5xTiQrI
Video introduction of our company : /watch?v=ajPDe3rivQU
Dongyue Enterprise Profile:
Dongye block making machine equipment :
Why Choose us?
