Specifications
4T steam boiler:boiler,coal boiler,coal and waste boiler
High-efficiency and High-quality
used in regular steam
4t steam boiler introduce
coal and waste boiler,coal boiler,waste boiler,waste heat boilers,steam boiler
1.4T steam boiler introduction
1).Automatically working acrooding to users' setting program.
2).Heating area is much larger , effective.
3).Equippted with mutiple chaining protection , in addition of independent water lever alarm and tribling pressure protection alarm to ensure the boiler works safely .
4).With imported color stainless steel , the boiler not only beautiful but also will never rust.
2.4T boiler technical parameter
Boiler model T/H 4 |
Rated outlet pressure Mpa 1.25 |
Rated outlet steam temperature 194 °C |
Boiler heating surface 115.3 m2 |
Grate area 4.6 m2 |
Economizer heating surface 37 m2 |
Water pressure test 1.65 Mpa |
Adaptation coal II III |
The amount of operating cost of coal at full load 649Kg/h |
Identification of thermal efficiency 83.27% |
Dust emission concentration 28 T |
Boiler Dimensions L*W*H 8260*5197*3862 |
Combustion Grate |
Fan Y9-26 NO 8C Q=12488H=3524 N=22KW |
Blower G6-41 NO 6.4A Q=5746H=1685 N=5.5KW |
Coal loader Model: SMJ-4 |
Mucking machine GBC-4 N=1.5KW |
Control box GL-5P CVT |
Water pump DG6-25*10 N=11KW |
3.Product features
1).The design of double drum, assemble type, chain grate, and monolayer arrangement of the boiler room features the following advantages: compacts structure, large heating surface, safe and reliable operation, short construction period, and low installation cost ect.
2).The furnace shall employ stuff device and cyclone reburning chamber, decreasing the dust contained in the flue gas. The tail shall be equipped with gas handing equipment, which shall make the dust emission concentration to reach to the national primary standard.
3).The feeding device with rational structure shall use mechanical bond wind feeding, featuring the following advantages: uniform, reliable, and high mechanization degree.
4).The application of small roller structure and boundary grate chip to grate and other patent technology, shall improve the reliability of the operation for the boiler.
5).The sealed wind chamber and bilateral grate air register are national patent technology, and the machining cone seal structure shall improve the grate wind sensitivity.
