Circulating Fluidized Bed Boiler Bituminous Coal/anthracite/lean Coal/lignite/gangue/slime Boiler
US$ 6,000 - 150,000
MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Type:
Natural Circulation
Usage:
Industrial
Payment & Shipping
Payment Methods:
Port of Shipment:
QINGDAO
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Germany Technical Dongyue Brand Autoclave Aerated Concrete Blocks Production LineUS$ 500,000 - 4,000,000MOQ: 1 Set -
Q Series Heat Recovery Boiler for SaleUS$ 3,000 - 50,000MOQ: 1 Set
-
Waste Heat Water BoilerNegotiableMOQ: 1 Set
-
Packaged Steam Boiler Coal Fired Steam Boiler Industial Steam BoilerUS$ 3,000 - 200,000MOQ: 1 Set
-
Q Series Waste Heat Recovery Steam BoilerUS$ 20,000 - 300,000MOQ: 1 Set
Condition
New
Type
Natural Circulation
Usage
Industrial
Structure
Water Tube
Pressure
Low Pressure
Style
Horizontal
Fuel
Gas-fired
Place of Origin
Shandong, China
Brand Name
DONGYUE
Model Number
Circulating fluidized bed boiler
Output
Steam
Certification
ISO9001 Certificate ,ASME(S) Certificate
After-sales Service Provided
Engineers available to service machinery overseas
Specifications
Circulating fluidized bed coal boiler1. ISO9001/ASME(S) Certificate .
2.Rated working pressure(Mpa):3.82/5.3
3.high efficie
Main performance of Circulating fluidized bed coal boiler
| Boiler type | LG-130/5.3-M |
| Rated output(t/h) | 130 |
| Rated working pressure(Mpa) | 5.3 |
| Rated steam temperature °c | 450 |
| Feedwater temperature°c | 150 |
| Combustion mode | Circulating fluidized bed boiler |
| Applicable fuel | petroleum coke |
| Fuel particle size requirements(mm) | ≤10 |
| Limestone particle size requirements(mm) | ≤2 |
| Drum centerline elevation(mm) | 33000 |
| Boiler proper highest point elevation(mm) | 54270 |
| Boiler type | LG-75/3.82-M |
| Rated output(t/h) | 75 |
| Rated working pressure(Mpa) | 3.82 |
| Rated steam temperature °c | 450 |
| Feedwater temperature°c | 130 |
| Combustion mode | Circulating fluidized bed boiler |
| Applicable fuel | bituminous coal/anthracite/lean coal/lignite/gangue/slime /petroleum coke |
| Fuel particle size requirements(mm) | ≤8 |
| Limestone particle size requirements(mm) | ≤2 |
| Drum centerline elevation(mm) | 28300 |
| Boiler proper highest point elevation(mm) | 33950 |
| Boiler type | LG-130/5.3-M |
| Rated output(t/h) | 130 |
| Rated working pressure(Mpa) | 5.3 |
| Rated steam temperature °c | 450 |
| Feedwater temperature°c | 150 |
| Combustion mode | Circulating fluidized bed boiler |
| Applicable fuel | petroleum coke |
| Fuel particle size requirements(mm) | ≤10 |
| Limestone particle size requirements(mm) | ≤2 |
| Drum centerline elevation(mm) | 33000 |
| Boiler proper highest point elevation(mm) | 54270 |
