High Speed Drinking Water Filling Machine for PET Bottle

Zhangjiagang Jiazhou Machinery Co., Ltd.
High Speed Drinking Water Filling Machine for PET Bottle thumbnail-1
High Speed Drinking Water Filling Machine for PET Bottle thumbnail-2
High Speed Drinking Water Filling Machine for PET Bottle photo-1
High Speed Drinking Water Filling Machine for PET Bottle photo-2
US$ 10,000 - 40,000 MOQ: 1 Unit
Key Specifications
Get Latest Price
Condition:
New
Application:
Beverage, Other, Beverage, Drinking Water
Packaging Type:
Bottles
Contact Supplier Request Quote Chat Now
Payment & Shipping
Payment Methods:
Port of Shipment:
FOB Shanghai for Drinking water filling machine
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Application Beverage, Other, Beverage, Drinking Water
Packaging Type Bottles
Packaging Material Plastic
Automatic Grade Automatic
Driven Type Pneumatic
Voltage 220V
Power 11KW
Place of Origin Jiangsu, China
Brand Name JZ
Model Number CGF
Dimension(L*W*H) 5450*4500*2900
Weight 9T
Certification CE ISO
After-sales Service Provided Engineers available to service machinery overseas

P/roduct informationZhangjiagang Jiazhou Machinery Co., Ltd.

Product descriptionHigh Speed Drinking water filling machine for PET Bottle



Drinking water filling machine introduction



This mineral water filling machine (filling water machine) is a standard 3-in-1 monoblock for PET bottles. Continuous rinsing, high speed gravity/pressure filling and capping are composed in one machine. It applies for filling drinking water, pure water and mineral water with max. capacity of 40,000BPH (500ml).

Drinking water filling machine features

  • This mineral water filling machine adopts advanced high speed gravity/pressure filling. This realizes high speed, low reflux rate and accurate liquid level.
  • We adopt magnetic torque capping head, high efficiency and low reject ration.
  • Cap unscrambling and feeding unit will take out the reversed caps automatically.
  • No bottle no filling, no bottle no capping. Once the caps are lack, the machine will stop automatically.
  • In the rinsing, filling and capping process, the bottles are transferd by neck-hanging, which realizes contactless with the bottle screw. This avoids second pollution to the material. For large capacity of production line, the bottles can be carried by clamps in whole process. This makes it much easier to suit for different capacity of bottles.
  • The water pipes for rinsing water is made of stainless steel 304.
  • According to customer’s requirement, the bottles can be washed by aseptic air or/and aseptic water.
  • The machine is controlled by PLC and HMI. It is easy for operation and maintenance.
  • Safety device is thoroughly installed in any of our machine.
  • All the electrical parts and pneumatic parts are from world famous manufacturers.
Product displayHigh Speed Drinking water filling machine for PET Bottle

 High Speed Drinking water filling machine for PET Bottle



High Speed Drinking water filling machine for PET Bottle



High Speed Drinking water filling machine for PET Bottle

Product ParametersHigh Speed Drinking water filling machine for PET Bottle
modelCGF 16-12-6CGF 16-16-6CGF 18-18-6CGF 24-24-8CGF 32-32-8
production(500/m/bottle/h)3000-40004000-50005000-60008000-1000010000-12000
filler valves1216182432
rinser grippers1616182432
capper header666810
suitable bottle shapecircular or square
bottle diameter(mm)φ50-φ90
bottle height(mm)150-310
Compressed air pressure(MPa)0.3-0.7
washing mediumaseptic water
washing water's pressure(MPa)0.25
Total output (KW)2.22.2346.2
oerall dimensions(mm)2350x1610x22502350x1750x22502480x1960x22503010x2180x24004000x2200x2500
(weight kg)22002500280035006000



 High Speed Drinking water filling machine for PET Bottle
