Small Bottle Water Filling Machine/Mineral Water Filling Line/Water Filling Machine,Mineral Water Bottling Plant
- 30 Unit / Units per Month
- SHANGHAI
- T/T D/P D/A Credit Card
- Cheapest Automatic Bottle Blowing Machine Prices/factory price automatic bottle shrink wrapping machine
- PET bottle making machine/nice plastic bottle making machine price/high quality plastic bottle blowing machine
- Top quality china automatic machines to make plastic bottles/bottle blowing machinery/Pet Bottles Blowing Machine 750ml
- Chinese PET water bottle blowing machine/equipment / automatic bottle Blowing machinery
- Low price Beverage drinking PET bottle blowing machinery/fully automatic pet bottle blowing machine
- high quality bottle blowing machine/automatic shrink wrapping machine/water bottle blowing machine
Product Details
Condition: | New | Application: | Beverage | Packaging Type: | Barrel, Bottles, Cans |
Packaging Material: | Plastic, Wood | Automatic Grade: | Automatic | Driven Type: | Electric |
Place of Origin: | Jiangsu, China | Brand Name: | JZ | Model Number: | CGF |
Weight: | 5000kg | Certification: | ISO | After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
Small bottle water filling machine/juice filling line/water filling machine,mineral water bottling plant
Characteristics & Advantage
- It is designed more compact, more stable of controlling system, adopts with German FESTO, easy to operate and high automatically.
- Using high accuracy and high speed filling valve. Liquid level is more accurate without water loss, ensuring the quality of filling.
- Capping heads use magnetic torque device, ensuring the capping effect and protect the bottle cap.
- Using frequency conversion motor of German SEW, can be more convenient to adjust the capacity.
- Controlling system has the liquid level control function, lack of cap detection alarm function, automatic alarm for card bottles function etc.
- Using advanced touch screen control, can realize human-machine conservation.
Turn-key solution expert mineral water filling machine price
Technical Data
Model | 14-12-5 | 24-24-6 | 32-32-8 | 40-40-10 | 50-50-12 |
Capacity | 5000 (500ml) | 10000 | 15000 | 18000 | 22000 |
Suitable bottle type | diameter 50-90 mm, height 165-290 mm | ||||
Gas consumption | 0.8 m3/min | ||||
Air pressure | 0.7 Mpa | ||||
Total power | 3 kw | 3.5 kw | 5.5 kw | 9 kw | 11 kw |
Total size | 2200×1550×2650 mm | 3130×2250×2100 mm | 3430×2630×2750 mm | 4300×2930×2750 mm | 5004×3826×2750 mm |
Total weight | 2000 kg | 5000 kg | 7000 kg | 7800 kg | 8200 kg |
