Good Quality Automatic Drink Water Bottling Machine

Good Quality Automatic Drink Water Bottling Machine photo-1
Good Quality Automatic Drink Water Bottling Machine photo-2
Good Quality Automatic Drink Water Bottling Machine photo-3
Good Quality Automatic Drink Water Bottling Machine photo-4
US$ 1,000 - 12,000 MOQ: 1 Unit
Key Specifications
Get Latest Price
Condition:
New
Application:
Other, Water, Drinking Water
Packaging Type:
Bottles
Payment & Shipping
Payment Methods:
Port of Shipment:
FOB Shanghai for water bottle filling machine price
Delivery Detail:
Delivery time depends on order quantity.
Condition New
Application Other, Water, Drinking Water
Packaging Type Bottles
Packaging Material Plastic
Automatic Grade Automatic
Driven Type Electric
Voltage 220V
Power 2.2KW
Place of Origin Jiangsu, China
Brand Name JZ
Model Number CGF
Dimension(L*W*H) 2900*2700*2950mm
Weight 2.5T
Certification CE ISO
After-sales Service Provided Engineers available to service machinery overseas

P/roduct informationZhangjiagang Jiazhou Machinery Co., Ltd.

Product descriptionGood quality automatic drink water bottling machine

1.This machine has a compact structure, completed control system, easy to operate and highly automated.
2.By changing the star-wheel, screw bottle inlet and arc guide plate can realize to change the bottle shape.
3.The parts that direct contact with product are made of food grade stainless steel and no technology corner pockets and easy to clean.
4.By adopting high speed filling valve, the liquid level is precise and no waste. That guarantees the demand of filling technology.
5.The machine adopts high effective cap sorting system and completely self control and protective device.
6.The machine is equipped with perfect overload protective device that can keep the equipment and operator safely.
7.The control system has many functions, such as control producing speed, cap shortage detection, bottle block automatic stop and production counting etc.
8.The electric components and pneumatic components are all introduced from world famous brand products.

Product displayGood quality automatic drink water bottling machine



Good quality automatic drink water bottling machine



Good quality automatic drink water bottling machine



Good quality automatic drink water bottling machine





Product ParametersGood quality automatic drink water bottling machine
ModelCGF
18186
CGF
24248
CGF
323212
CGF
404015
CGF
505018
CGF
606020
Head of washing, filling, sealing18-18-624-24-832-32-840-40-1050-50-1860-60-20
Production capacity (bottle/hour)  3000-40005000-60007000-80009000-1000011000-1200015000
Suitable bottle diameter(mm)φ=50-100 H=150-310 330-1500mlφ=50-100 H=150-310 330-1500mlφ=50-100 H=150-310  330-1500mlφ=50-100 H=150-310  330-1500mlφ=50-100 H=150-310  330-1500mlφ=50-100  H=150-310  330-1500ml
Filling precision≤±5mm≤±5mm≤±5mm≤±5mm≤±5mm≤±5mm
Motor power3.84kw4.1kw5.6kw7.5kw9kw11kw
Filling pressure≤0.4≤0.4≤0.4≤0.4≤0.4≤0.4
Overall dimension     (mm)2400×1900
×2300
2800×2100
×2300
4200×2300
×2300
5000×2800
×2400
5900×3100
×2400
6500×3500
×2400
Weight(Kg)3000400050007500900011000



Good quality automatic drink water bottling machine

C/ompany informationZhangjiagang Jiazhou Machinery Co., Ltd.
Good quality automatic drink water bottling machine
O/ur advantageZhangjiagang Jiazhou Machinery Co., Ltd.
Good quality automatic drink water bottling machine
O/ur certificateZhangjiagang Jiazhou Machinery Co., Ltd.
Good quality automatic drink water bottling machine
N/etwork MarketingZhangjiagang Jiazhou Machinery Co., Ltd.
Good quality automatic drink water bottling machine
P/ackaging & shippingZhangjiagang Jiazhou Machinery Co., Ltd.
Good quality automatic drink water bottling machine
C/ontact usZhangjiagang Jiazhou Machinery Co., Ltd.
Good quality automatic drink water bottling machine
