Water Filling Machine 3 in 1
Main Configuration
1) Material of filling valve is SS304.
2) Material of rinse and rotary plate, machine table is stainless steel 304.
3) Main motor: ABB
4) Sliding bearing: Igus, Germany.
5) Transducer: MITSUBISH
6) Touch screen: DIGITAL
7) PLC: OMRON
8) Pneumatic components: FESTO, Germany.
9) Seals: National brand
10) Photocell switch and proximity switch: TURCK (Germany)
Technician parameters of water filling machine :
Model |
CGF16-12-6 |
CGF18-18-6 |
CGF24-24-8 |
CGF32-32-8 |
CGF40-40-10 |
CGF50-50-12 |
CGF60-60-15 |
|
Washing,-Filling-Capping |
16-12-6 |
18-18-6 |
24-24-8 |
32-32-8 |
40-40-10 |
50-50-12 |
60-60-15 |
|
Producing capacity (500ml) |
2000-4000 (bph) |
5000-7000 (bph) |
8000-12000 (bph) |
12000-15000 (bph) |
16000-20000 (bph) |
20000-24000 (bph) |
25000-30000 (bph) |
|
Applicable bottle (mm) |
φ=50-108 H=170-340 330ml-2.25L |
|||||||
Pressure (kg/cm2) |
2~3 |
|||||||
Outside vacuum pump power (kw) |
Main motor 1.5kw |
Main motor 2.2kw |
Main motor 3kw |
Main motor 4kw |
Main motor 7.5kw |
Main motor 9.5kw |
Main motor 12kw |
|
Overall dimension (mm) (LxWxH) |
2100x1400 x2500 |
2460x1720 x2650 |
3100x2100 x2650 |
3500x2500 x2650 |
4600x1800 x2650 |
5200x4500 x3400 |
6500x4500 x3400 |
|
Weight(kg) |
2500 |
3500 |
4200 |
5500 |
6800 |
7600 |
9800 |
|
Plastic Pure Mineral Water Filling Machine
