Concrete Pipe Cage Making Machine

Name: Concrete Pipe Cage Making Machine
Brand: JIAKE
SKU: 140420358
Availability: InStock

Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)

Key Specifications

Place of Origin:

Hebei, China

Brand Name:

JIAKE

Model Number:

JK-1250

Hebei Jiake Welding Equipment Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Tianjin China

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Hebei, China

Brand Name JIAKE

Model Number JK-1250

Tube Diameter 300-4000

Weight 7000-12000kg

Usage weld concrete steel bar cage

Specifications

concrete pipe cage making machine
Diameter:1500,2000mm or customized
PLC automatic controller

concrete pipe cage making machine

Concrete pipe cage welding machine for cylindrical and prismatic piles with welded spiral and programmable pitch.

Two workers only are required.

Integrated production time.

Programming and controlling by computer.

Simple and efficient feeding system and functioning cycle.

The spacing of cross-coil can be adjusted, and the spacing of the line-rebar can be adjusted too.

Item & Model	JK-1250	JK-1500	JK-2000	JK-2500
Cage diameter	300-1250	500-1500	500-2000	500-2500
Max length of cage	Standard 12m, or customized 15m, 18m, 21m, 24m, 27m, 30m, 33m, 36m
Max cage weight	3000kg	4500kg	6000kg	8000kg
Line-rebar dia.	12-40mm
Cross-coil dia.	5-16mm
Space of cross-coil	50-500mm adjustable
Rated power	10KW	11KW	23KW	23KW
Overall dimension	282.32.3m	282.52.6m	284.23.3m	284.63.8m
