Reinforcing Wire Mesh Welding Machines JK-RM-2500B
reinforcing wire mesh welding machines JK-RM-2500B
Model |
JK-RM-2500B |
Wire diameter |
5-12mm |
Line wire spacing |
100-300mm |
Cross wire spacing |
CNC fine tuning |
Cross wire length |
Max.2.5m |
Line wire length |
Unlimited
|
Welding spot |
24 pcs |
Wire material type |
Pre-straightened and pre-cut, high quality low carbon steel wire, cold-drawn steel wire, cold-rolled ribbed bar with clear surface and without rusting, lime drawing powder, water stain, scabbing-- |
Welding speed |
40-65 cross wires/min |
Power mode |
Pneumatic system+servo motor+PLC+touch screen |
Welding capacity |
150KVAX12 |
Power supply |
≥400KVA, 240mm² aluminum wire, distance between machine and power supply less than 100m |
Voltage |
3-phase 380V/440V/415V220V 50HZ/60HZ or as required |
Dimension |
14*3.1*2.3m |
Weight |
6.5T |
Transformer external electrode |
30*30 mm red copper*2pcs |
Down electrode holder |
40*100*120mm red copper |
Upper electrode holder |
40*70*110mm red copper |
electrode |
30*30*50mm chromium zirconium coppe |
Down connecting wire |
20*40mm red copper |
Upper connecting wire |
600mm²red copper
|
Frequency converter |
Delta VE+ Omron encoder |
PLC |
Panosonic FPX series |
Touch screen |
Weinview MT6071IE |
Other appliances in electric cabinet |
Apots Schneider, Tengen, Meanwell Taiwan and so on |
Transformer |
New efficient epoxy mastic with water cooling system |
Motor |
Brake motor matching helical gear reducer |
Input line wire trunking |
Springiness |
shell structure, wall structure, reinforced concrete mesh, retaining wall reinforcement, floor boards, welded wire fencing, barrier fence, metal fence, fine mesh, fence netting, welded nets, temporary fencing, security fence, safety fencing, safety/security enclosures, security barriers, prison mesh, prison security fencing, rigid mesh, wire mesh partitions,construction fence, concrete meshes, prefabricated steel reinforcing material, fabricated stainless steel wirework, welded mesh fabric, steel wire mesh, engineered mesh, steel fabric mesh, welded screens, electro welded steel wire mesh, etc.
A: Pre-sale service; plant layout design, technical consulting, feasibility studies, cost and ROI analysis;
B: sales services: installation and commissioning, operator training, electrician and mechanic training;
1.Equipment installation and commissioning: assist and guide customer coordinate the equipment layout according to the actual situation, make reasonable arrangements for the overall planing of the installation location. Assigned technician to provide equipment installation, operation, ancillary facilities, production, repair, maintenance services and answer the relevant questions.
2.Training operation and maintenance personnel: our company will provide training of the operation and maintenance personnel according to customer’s requirement.
C: after-sale service; supply spare parts and provide after-sale services
1.supply of spare parts: keep records for each customer, provide long-term supply of spare parts, and send it to customers hand with the fastest speed according to customers’ requirement.
2.Unexpected emergency repair service: once the equipment have malfunction, and the user unable to rule out, we will arrange technician to the user factory in the soonest time, solve the trouble and resume production in time.
Contact: Miss lee
Skype: qq1815361000
Mobile/Wechat:+86 15324391556
Hebei Jiake Welding Equipment Co.,Ltd
Address:Wire Mesh Insdustrial Zone, Anping County, Hebei Province, China
