Jaw Crusher,stone Crusher,ballast Crusher

Condition:New

Type:Jaw Crusher

Application:Mining

Motor Type:AC Motor

Power(W):160kw

Capacity(t/h):265-402

Dimension(L*W*H):3340*3350*3720mm

Weight:45t

Certification:ISO CE

Warranty:12 Months

Feed opening:1000*1200

Max feeding size:850mm

Used for:Primary Jaw Crusher

With larger feed openings and bigger crushing strokes, the Jaw Crusher is suitable for crushing big size lumps in large quantity. Jaw Crushers are especially recommended for primary and concrete recycling, river stones, tough ores, for a very long life. From the welded steel base to the rugged eccentric shaft, the jaw crusher is built with brute strength with quality bearings.

The Jaw Crusher is configured for primary crushing of even the hardest rock. Incoming material is crushed between the jaw crusher’s fixed plate and movable plate through advancing and retreating motions of the jaw crusher pitman arm. The Jaw Crusher main shaft bearing includes a dust seal with oil bath lubrication

1.Roller bearings provide strength & safety. Oil bath lubrication ensures longer service life.

2.Toggle plate, toggle block, and toggle seat protect the jaw crusher from damage caused by uncrushable material in the crushing chamber. This construction helps to maintain a stable crushing angle.

3.Simple & quick discharge gap adjustment, precise product grain distribution.

4.Large & deep crushing chamber with sharp crushing angle, to achieve a very high crushing ratio.

5.The Jaw Crusher with bigger feed opening and longer pitman arm is especially suitable for primary crushing.

6.Recommended for big lumps & large quantities, for primary crushing of limestone, river stone, tough ores, and concrete recycling.

Feeding Port Size(mm):600X400-1500X1200

Max. Feeding Size(mm):340-1030

Discharge Port Size(mm):50-300

Capacity(t/h):26-850

Motor Power(kW):30-265

Weight(kg):6320-78000
