Supply All Kinds of Bearing 6322 Single-row Radial Deep Groove Ball Bearing

Supply All Kinds of Bearing 6322 Single-row Radial Deep Groove Ball Bearing thumbnail-1
Supply All Kinds of Bearing 6322 Single-row Radial Deep Groove Ball Bearing photo-1
US$ 34 - 34 MOQ: 20 Pieces
Key Specifications
Get Latest Price
Brand Name:
KOYO
Bore Size:
110,
Outside Diameter:
240,
Contact Supplier Request Quote Chat Now
Jinan Kelunte Bearing Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Brand Name KOYO
Bore Size 110,
Outside Diameter 240,
Model Number 6322
Precision Rating P0 P6 P5 P4
Seals Type OPEN Z ZZ RS 2RS
Number of Row Single Row
Place of Origin Shandong, China

Specifications

6322 single-row radial deep groove ball bearing
1.ISO 9000:2001
2. Gcr 15
3. chrome steel
4. large stock

Supply all kinds of bearing 6322 single-row radial deep groove ball bearing





Product Description

6322 deep groove ball bearing's details:
1. Material: Chrome steel Gcr15
2. Inner diameter: 110mm
3. Grade: P0
4. ISO9001:2008 certification
5. Type: open, ZZ, 2RS,N


Inner Diameter

110mm


Outer Diameter

240mm


Thickness

50mm


Number of Sphere

8


Bearing Type

6322 Deep Groove Ball Bearing


Type of Cage

Crown

Sleeve Chuck


Material

Chrome Steel Gcr15


Shield

6322 ZZ    shield

6322 2RS   seal

6322 ZRS   shield and seal

6322 NRS

6322 ZNR


Tolerance

0-15micronmeter


Radial Internal Clearance

C0




Deep groove ball bearing are used in a particularly wide variety of applications. Consequently, they are available in many executions and sizes. The standard range comprises the following types:
1:Single row deep groove ball bearings
2:Energy efficient deep groove ball bearing
3:Single row deep groove ball bearing filling slots
4:stainless steel single row deep groove ball bearings
5:Double row deep groove ball bearings
6:Single row hybrid deep groove ball bearings
7:Single row deep groove ball bearing for high temperature
8:cam  rollers
9:polymer ball bearings
Application: transmission ,instrumentation ,motors ,household appliance, internal combustion engines, transport vehicles, agricultural machinery, engineering machinery.

deep groove ball bearings series



Bearing No. Boundary dimensions Basic load ratings (kN) Limiting speed Mass
mm Dynamic Static rpm Kg
d D B rs min Cr Cor Grease Oil
6300 10 35 11 0.6 7.65 3.48 23000 27000 0.053
6301 12 37 12 1 9.72 5.08 20000 24000 0.061
6302 15 42 13 1 11.5 5.42 17000 21000 0.08
6303 17 47 14 1 13.5 6.58 16000 19000 0.109
6304 20 52 15 1.1 15.8 7.88 14000 17000 0.142
6305 25 62 17 1.1 22.2 11.5 12000 14000 0.219
6306 30 72 19 1.1 27 15.2 10000 12000 0.349
6307 35 80 21 1.5 33.2 19.2 8800 10000 0.455
6308 40 90 23 1.5 40.8 24 7800 9200 0.639
6309 45 100 25 1.5 52.8 31.8 7000 8200 0.873
6310 50 110 27 2 62 38.3 6400 7500 1.07
6311 55 120 29 2 71.6 45 5800 6800 1.37
6312 60 130 31 2.1 81.9 52.2 5400 6300 1.7
6313 65 140 33 2.1 92.7 59.9 4900 5800 2..08
6314 70 150 35 2.1 104 68.2 4600 5400 2.52
6315 75 160 37 2.1 113 77.2 4300 5000 3.02
6316 80 170 39 2.1 123 86.7 4000 4700 3.59
6317 85 180 41 3 133 96.8 3800 4500 4.23
6318 90 190 43 3 143 107 3600 4200 4.91
6319 95 200 45 3 153 119 3300 3900 5.67
6320 100 215 47 3 173 141 3200 3700 7
6321 105 225 49 3 184 153 3000 3600 8.05
6322 110 240 50 3 205 180 2900 3400 9.54
6324 120 260 55 3 207 185 2600 3100 12.4
6326 130 280 58 4 229 214 2400 2800 15.3
6328 140 300 62 4 253 246 2200 2600 18.5
6330 150 320 65 4 274 284 2100 2400 22
6332 160 340 68 4 278 286 1900 2300 26
6334 170 360 72 4 325 355 1800 2100 30.7
6336 180 380 75 4 355 405 1700 2000 35.6
6338 190 400 78 5 355 415 1600 1900 41
6340 200 420 80 5 410 500 1500 1800 46.3
6344 220 460 88 5 410 520 1400 1600 60.8
