Brand Name CLUNT
Bore Size 20,
Outside Diameter 72,
Model Number 6404
Precision Rating P0 P6 P5 P4
Seals Type OPEN RS 2RS Z ZZ
Number of Row Single Row
Place of Origin Shandong, China

Use in fan motor bearing 6404 deep groove bearing with row material

Product Description

Use in fan motor bearing 6404 deep groove bearing with row material





1.The discription of  deep groove ball bearing

Deep groove ball bearings are non-separable and require little attention or maintenance in service, capable of operating at high speeds and are widely used radial bearings. The inner and outer ring of single row deep groove ball bearings have a deep groove raceway, the bearings are mainly used to carry radial loads and a part of axial loads in two directions. This kind of bearing can carry much heavy axial loads after the increase of radial clearance, thus, it can take the place of high speed angular contact ball bearings. Deep groove ball bearing have various types in structure, beside open type bearings, shield or seals at both side can also be provided

2. The structure of bearing  6404

 Use in fan motor bearing 6404 deep groove bearing with row material



3.The detailed information of bearing 6404



symbol 6404
mass [kg]: 0.4
basic load rating (dynamic) C [kN] 30.05
basic load rating (static) Co [kN] 15
limiting speeds (grease) [min-1] 10000
limiting speeds (oil) [min-1] 13000
d [mm] 20
D [mm] 72
B [mm] 19
rs min [mm] 1.1
D1 [mm] 68.81
a ~ [mm] 3.28
b [mm] 1.9
ro max [mm] 0.6

4. Feature of deep groove ball  bearings

1,A variety of models of deep groove ball bearing are used in a widely field .
2,Simple structure and the use of maintenance are convenience.
3,Mainly used to bear radial load, but also bear certain axial load, the radial bearings Clearance increase, angular contact ball bearings with the performance, can withstand higher axial loads. 4,bearing such friction coefficient, limit high-speed, size and scope of the changes varied.

5,it adapts movement temperature from -30°C to +120°C.
6,it don’t need to lubricate again in the process, because it taken a dust palliative cover and taken to seal completely a turn the bearings assemble have already stuffed with just the right amount of lubrication fat.
7,it don’t need to clean again when it should be heated.

5. Mounting :

The method of mounting rolling bearings strongly affects their accuracy,life,and performance,so their mounting deserves careful attention.It is recommended that the handling procedures for bearing be fully investigated by the design engineers and that standards be established with respect to the following items: 1,Clearing the bearings and related parts.

2,Checking the dimensions and finishing of related parts.

3,Mounting procedures.

4.Inspection after mounting.

5,Supply of lubricants.

6.The type of deep groove ball  bearing

Single Row deep goove ball bearing

Double Row deep groove ball bearing



 7.Model number of deep groove ball bearings





ITEM DIMENSION(mm)
  d D B
6000 10 26 8
6001 12 28 9
6002 15 32 10
6003 17 35 12
6004 20 42 12
6005 25 47 13
6006 30 55 14
6007 35 62 15
6008 40 68 16
6009 45 75 16
6010 50 80 18
6011 55 90 18
6012 60 95 18
6013 65 100 20
6014 70 110 20
6015 75 115 22
6016 80 125 22
6017 85 130 24
6018 90 140 24
6019 95 145 24
6020 100 150 24
6021 105 160 26
6022 110 170 28
6024 120 180 28
6026 130 200 55
6028 140 210 32
6030 150 225 35
6200 10 30 9
6201 12 32 10
6202 15 35 11
6203 17 40 12
6204 20 47 14
6205 25 52 15
6206 30 62 16
6207 35 72 17
6208 40 80 18
6209 45 85 19
6210 50 90 20
6211 55 100 21
6212 60 110 22
6213 65 120 23
6214 70 125 24
6215 75 130 25
6216 80 140 26
6217 85 150 28
6218 90 160 30
6219 95 170 32
6220 100 180 34





Pictures of product

 Use in fan motor bearing 6404 deep groove bearing with row materialUse in fan motor bearing 6404 deep groove bearing with row materialUse in fan motor bearing 6404 deep groove bearing with row materialUse in fan motor bearing 6404 deep groove bearing with row materialUse in fan motor bearing 6404 deep groove bearing with row materialUse in fan motor bearing 6404 deep groove bearing with row material



Company Information

Use in fan motor bearing 6404 deep groove bearing with row materialUse in fan motor bearing 6404 deep groove bearing with row materialUse in fan motor bearing 6404 deep groove bearing with row material

Packaging & Shipping

Use in fan motor bearing 6404 deep groove bearing with row material

Our Services
We are 100% manufacture. We can supply you technical support.
We have strict quality control processes. We supply high quality bearings with fair price.
We accept small quantity.
We may supply other globle brand bearings and offer buyer labels.
We can manufacture any bearings according to customer's drawings
