Home > Products > CF series hammer mill > poultry feed grinder, wood hammer mill, straw hammer mill, corn hammer crusher
poultry feed grinder, wood hammer mill, straw hammer mill, corn hammer crusher
- 1000 Unit / Units per Month
- qingdao
- T/T Credit Card PayPal
You May Like
-
11KW380V 50HZ 3 phase poultry feed and wood sawdust hammer mill
-
animal feed hammer mill/crusher
-
rubber tree branches hammer mill corn stalk hammer mill , wood hammer mill with CE
-
New design corn fodder grinder hammer mill with CE
-
wood crusher /tree branches / agriculture stalk grinder big diameter wood into powder
-
wood chipper tree branches Coconut shell Hazelnut shell straw hammer mill
Product Details
Condition | New | Place of Origin | Shandong, China | |
Brand Name | chengda machine | Model Number | CF158.198.420.500 | |
Type | Mill Machine | Voltage | 380v | |
Power(W) | 2.2kw to 22kw | Dimension(L*W*H) | 124*97*106 CM | |
Weight | 840 kg | Certification | CE | |
Warranty | 1 years |
Product Description
Specifications
1.power:gasoline, diesel engine and Emotor2.output:60-1200kg//h
3.CEcertification
4.1 years warranty
5. prompt delivery
Product Feature:
1. Simple and Automatic Operation;
2. Easy Maintain;
3. It can be combined according to your requests, no limitation on the places;
4. It realizes the perfect combination on the chipping and crushing.
The Introduction of the Hammer Mill
1.Hammer Mill is used for crushing small diameter raw materials, which are no more than 100mm such as corn straw,tree branches and so on. after crushing, the diameter of the final products could be 3-5mm
2.This hammer mill is mainly composed of casing, rotor, hammers and bars. The case is divided into two parts: up and down, which is connected by welding the cut steel; other parts are connected by screws. The one inside of case is high manganese steel lining board, which is easy to change when wore out.
3. In order to avoid clogging, humidity of crushed material should below 10%-50%.
the Hammer Mill is the most ideal milling equipment of all kinds of wood pieces, straw, grass, stalk, tree branches, waste cardboard, bamboo, wood scrap, corn stalk, peanut shell, wheat stalk, wood fuel, cotton stalk, biomass shell and so on, which can crush the raw material into small particles with size 3~5mm.
The machine includes airlock, blower, cyclone. It is equipped with high carbon steel blade and works with high efficiency and gains more good reputation from European users.
Hammer Mill IntroductionSpecification:
Model No. | Power | Output(kgs/h ) | NW/GW(kg) | Packing size(cm) | Remark |
CF158 | 2.2kw/220V | 50-80 | 75/95 | 48*58*63 | CE motor |
CF158 | 3 kw/380V | 50-180 | 75/95 | 48*58*63 | CE motor |
CF198A | 7.5HP | 150-450 | 120/140 | 90*58*102 | gasoline engine |
CF198B | 4kw/380V | 150-450 | 120/140 | 90*58*102 | CE motor |
CF420A | 15HP | 360-650 | 330/360 | 147*73*109 | diesel engine |
CF420A | 22HP | 400-850 | 330/360 | 147*74*111 | diesel engine |
CF420B | 7.5kw/380V | 350-650 | 260/320 | 112*82*107 | CE motor |
CF420B | 11kw/380V | 300-800 | 320/360 | 112*82*107 | CE motor |
CF500A | 55HP | 850-1500 | 800/840 | 150*142*123 | diesel engine |
CF500B | 22kw/380V | 800-1200 | 600/630 | 124*97*106 | CE motor |
we also have the pellet mill for your choose.
some pictures as below:
we also supply the pellet cooler and wood cutter:
if you need more information, feel free contact me.
