FRS Sand Mill
- Shanghai
- T/T
You May Like
-
Farfly Newest Hydraulic Lifting Coating Production Basket Mill With Fixed Cover
-
FTM Liquids Paint Hydraulic Lifting Basket Mill With Cover
-
FTM Paint Hydraulic Lifting Basket Mill With Cover
-
FTM Paint Batch Production Hydraulic Lifting Basket Mill With Cover
-
FTM Paint High Effection Basket Mill With Cover
-
High Quality Paint Horizontal Sand Mill
Product Details
| Condition | New | Type | Sand Mill | |
| Product Type | Paint | Place of Origin | Shanghai, China | |
| Brand Name | FARFLY | Model Number | FRS | |
| Voltage | customized | Power(W) | customized | |
| Dimension(L*W*H) | customized | Weight | customized | |
| Certification | CE | Warranty | 1 year | |
| After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
FARFLY FRS Sand mill
Applicable range:
Offser printing lnk,Screen Pringting Lnk,Condensed lnk,UV Printing lnk,Gravure printing lnk,Waterborne Printing lnk.
Characters:
-Strong versatility, easy operation, PLC is used for control ,analogous drawing and touch screen are available (optional).
-Conic grinding and mixing tank provides the best grinding effect.
-Self-clean,high-precision separating ring and grinding media with 0.8~2.5mm are acceptable.
-Small processing area and closed grinding ensures the least pollution.
-Grinding area made of special anti-wearing alloy material ensures long service life.
-All imported high-precision bearings and double-acting mechanical sealing ensure service life and stability pf equipment.
- Internal circulation cooling/heating integrated system suiting temperature-sensitive materials.
Technical data:
Type | FRS-10 | FRS-15 | FRS-20 |
Motor power KW | 22~37 | 45~55 | 55~75 |
Grinding medium (mm) | 0.8~2.0 | 0.8~2.5 | 1.6~2.5 |
Capacity (kg/h) | 50~300 | 150~500 | 250~800 |
Barrel volume (L) | 10 | 15 | 20 |
Compressed air (bar) | 2~6 | 2~6 | 2~6 |
Width(mm) | 1100 | 1650 | 1680 |
Length(mm) | 1550 | 2000 | 2020 |
Height (mm) | 1600 | 2500 | 2550 |
Height of outlet (mm) | 1100 | 1500 | 1540 |
Weight(kg) | 1200 | 3000 | 3800 |
