Paint Cheap Vertical Basket Mill

Paint Cheap Vertical Basket Mill thumbnail-1
Paint Cheap Vertical Basket Mill thumbnail-2
Paint Cheap Vertical Basket Mill thumbnail-3
Paint Cheap Vertical Basket Mill photo-1
Paint Cheap Vertical Basket Mill photo-2
Paint Cheap Vertical Basket Mill photo-3
US$ 8,500 - 9,500 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Type:
Sand Mill
Product Type:
Paint
Contact Supplier Request Quote Chat Now
Shanghai Farfly Energy Technology Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai or china port
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Type Sand Mill
Product Type Paint
Place of Origin Shanghai, China
Brand Name FARFLY
Model Number FTM500 basket mill
Voltage 220v/380v or customized
Power(W) 18.5kw
Dimension(L*W*H) 2200*2100*1100mm
Weight 1.2MT
Certification CE/ISO9001
Warranty 3 years for whole basket mill
After-sales Service Provided Overseas service center available

 paint cheap vertical basket mill

Description of basket mill :
1)Liquid circulation system is generated between the material feeding rotor and toothed dispersing disc and grinding beads with high hardness driven by the high-speed rotating rod in the basket result in outstanding milling effect.
2)Good milling fineness, high grinding efficiency, even particle distribution and the whole milling process is finished under closed condition.
3)Without dead corner, little residue, easy to clean and easy to change color or other products.
Advantages of FARFLY BASKET MILL:
--Adopts hydraulic lifting;
--Highest product qualities with exact productability;
--Simple and user-friendly machine design;
--Infinitely variable speed control by frequency converters with vector control;
--Quick detachable basket for repairing and clean out;
--Grinding process with high energy density.



Technical data:


Type
Voltage
(V)
Power
(Kw)
Speed
(rpm)
Batch
Volume
(L)
Basket
Volume
(L)
Lifting Height
(mm)
FTM-50
~380
2.2
0~1500
10~50
1
500
FTM-100
~380
4
0~1500
30~100
2
600
FTM-200
~380
7.5
0~1500
50~200
4
700
FTM-250
~380
11
0~1500
80~250
6
800
FTM-350
~380
15
0~1500
150~350
10
900
FTM-500
~380
18.5
0~1500
200~500
16
1000
FTM-1000
~380
22
0~1500
400~800
20
1100
FTM-1500
~380
30
0~1500
800~1200
25
1200
FTM-2000
~380
45
0~1000
1000~2000
37
1300
FTM-3000
~380
55
0~1000
1000~3000
51
1500
FTM-3500
~380
75
0~1000
1000~3500
75
1600
