Airport baggage weighing conveyor
Sketch Map of Weighing Conveyor
As part of the check-in and ticketing system, the weighing/labeling conveyor is the front-end equipment of the baggage handling system. On each end of the weighing/labeling conveyor, there shall be two photoelectric switches to measure the maximum size of the baggage. When the two photoelectric switches were both blinded by the moving baggage at the same time, this baggage shall be deemed as super-large baggage and shall be carried by the elevator. At the bottom of the frame of weighing/labeling conveyor, there shall be equipped with guide rail, guide pulley, leveler and locking device. The conveyor can run on the guide rail with the help of guide pulley. When the conveyor fails, it can be pulled out for maintenance.
Main Technical parameters of airport baggage weighing conveyor
|
Length of the conveyor(L) |
1200mm~2000mm |
Static load |
150kg/m |
Side plate |
GB304 |
|
Height of the belt surface(H1) |
330m~400mm |
Dynamic load |
50kg/m |
Lateral cover plate |
GB304 |
|
Height of the whole machine(H2) |
400mm~650mm |
Head roller |
Φ60mm |
End cover plate |
GB304 |
Belt width(W1) |
450mm~1000mm |
Tail roller |
Φ60mm |
Slinding bed board |
Q235 |
Side placte spacing(W2) |
480mm~1040mm |
Tension roller |
Φ60mm |
Fittings |
Q235 |
Conveyor width(W3) |
600mm~1200mm |
Electric roller |
Φ113mm/Φ135mm/Φ138mm |
Plug pin |
Q235 |
Speed |
21m/min~30m/min |
Electronic scale |
AccuacyIII GB I4249.2-93 III) |
Belt |
Anit-skid, antiflaming, antistatic |
Noise |
≤65dB(A) (Ground clearance of 1m,1m away from the sound source, environmental noise 50 dB(A)) |
||||
Structural representation
Optional size
Belt width
450mm,500mm,550mm,600mm,650mm,680mm,1000mmm and so on as you like
Conveyor length
1200mm,1300mm,1400m,1500m,2000mm and so on
